Alvanite

Zn2+Al4(V5+O3)2(OH)12 · 2H2O
IMA status
  • Approved
IMA symbol
Alv
Discovered
1959
Also known as
  • Alvaniet
  • Alvanitt

Where it forms, where it's found

Geological setting

In the oxidation zone of a vanadiferous clay-anthraxolite horizon.

Type locality
Kurumsak V Deposit
  1. Aksumbe
  2. Sozak District
  3. Turkistan Region
  4. Kazakhstan

44.3333°, 67.6333°

2recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103 – 3.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Pale bluish green to bluish black.
Streak
White
Cleavage
Perfect

On (010).

Fracture
Micaceous
Density
2.49 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 80 – 85°
Refractive index
1.658 – 1.714
Surface relief
High
Principal indices
nα 1.658 · nγ 1.714
Dispersion
r < v, strong
Michel-Lévy diagramhighlighted lineδ = 0.0560
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]560 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation560 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#15
Cell parameters
a = 17.808 Å · b = 5.132 Å · c = 8.881 Å
Cell angles
β = 92.11 °
Ratio a:b:c
1 : 0.288 : 0.499
Z
2
Morphology

In hexagonal platelets, micalike, with forms (001), (010), (100), and (101).

Twinning

Polysynthetic, parallel to (010).

Type-locality form

Micalike platelets.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2015.999319.980
52.34%
13AlAluminiumAluminium426.982107.928
17.66%
23VVanadiumVanadium250.942101.884
16.67%
30ZnZincZinc165.38065.380
10.69%
1HHydrogenHydrogen161.00816.128
2.64%
Total611.300100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Alvaniet
  • Alvanitt

In other languages

German
Alvanit
Italian
alvanite
Portuguese
alvanite
Russian
альванит

Classification

Strunz
10th ed.

8.FE.05

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.FPolyphosphates, Polyarsenates, [4]-PolyvanadatesDivision
  • 8.FEIno-[4]-vanadatesGroup
  • 8.FE.05AlvaniteSpecies
Dana
8th ed.

42.13.13.01

  • 42Hydrated Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 42.13MiscellaneousType
  • 42.13.13Alvanite GroupGroup
  • 42.13.13.01AlvaniteSpecies
CIM

21.3.2

  • 21Vanadates (and vanadates with arsenate or phosphate)Class
  • 21.3Vanadates of Al, rare earths, Pb, V or BiGroup
  • 21.3.2AlvaniteSpecies

Literature, links & citation

Citations
  1. 1959Fleischer, M. (1959) New Mineral Names. American Mineralogist, 44 (11-12). 1321-1329
  2. 1959Ankinovich, E.A. (1959) New vanadium minerals - satpaevite and al'vanite [alvanite]. Zapiski Vserossiyskogo Mineralogicheskogo Obshchestva, 88. 157-164
  3. 1990Pertlik, F., Dunn, P.J. (1990) Crystal structure of alvanite, (Zn,Ni)Al4(VO3)2(OH)12·2H2O, the first example of an unbranched zweier-single chain vanadate in nature. Neues Jahrbuch für Mineralogie, Monatshefte: 1990: 385-392.
  4. 1990Dunn, Pete J., Roberts, Andrew C., Pertlik, Franz (1990) Alvanite from Kazakhstan, U.S.S.R.: new crystallographic and chemical data. Mineralogical Magazine, 54 (377) 609-611 doi:10.1180/minmag.1990.054.377.13 DOI: 10.1180/minmag.1990.054.377.13
  5. 1992Jambor, L., 207, Edward S. Grew (1992) New Mineral Names. American Mineralogist, 77 (1-2) 207-213
