Ameghinite

NaB3O3(OH)4
IMA status
  • Approved
IMA symbol
Agh
Discovered
1966
IMA approved
1966
Also known as
  • Ameghiniet
  • IMA1966-034

Where it forms, where it's found

Geological setting

Formed in massive borax in a borate-rich playa.

Type locality
Tincalayu Mine
  1. Antofagasta de la Sierra Department
  2. Catamarca Province
  3. Argentina

-25.2691°, -67.0509°

1recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102 – 3/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Colourless
Tenacity
brittle
Cleavage
Very Good

(100), very good; (001) and (010), poor.

Fracture
Conchoidal
Density
2.030 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 33°
Refractive index
1.429 – 1.538
Surface relief
Low
Principal indices
nα 1.429 · nβ 1.528 · nγ 1.538
Dispersion
r<v weak
UV response
pale blue fluorescence and phosphorescence under SW and LW UV.
Michel-Lévy diagramhighlighted lineδ = 0.1090
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1090 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1090 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/c
Cell parameters
a = 18.45 Å · b = 9.89 Å · c = 6.32 Å
Cell angles
β = 104.3 °
Ratio a:b:c
1 : 0.536 : 0.343
Z
8
Morphology

Crystals are elongated along [010], may be bent or curved, showing (001), (010), (100), (110), (011), (101), (101), (310), to 5 mm; as cluster of crystals and nodular masses.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen715.999111.993
65.32%
5BBoronBoron310.81032.430
18.92%
11NaSodiumSodium122.99022.990
13.41%
1HHydrogenHydrogen41.0084.032
2.35%
Total171.445100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Ameghiniet
  • IMA1966-034

In other languages

French
ameghinite
German
Ameghinit · IMA 1966-034
Spanish
Ameghinita
Italian
ameghinite
Chinese
阿硼钠石

Classification

Strunz
10th ed.

6.CA.10

  • 6BoratesClass
  • 6.CTriboratesDivision
  • 6.CANeso-triboratesGroup
  • 6.CA.10AmeghiniteSpecies
Dana
8th ed.

25.03.01.01

  • 25Anhydrous Borates Containing Hydroxyl or HalogenClass
  • 25.03TriboratesType
  • 25.03.01— unnamed intermediate level —Group
  • 25.03.01.01AmeghiniteSpecies
CIM

9.1.10

  • 9BoratesClass
  • 9.1Borates of the alkalis and boric acidGroup
  • 9.1.10AmeghiniteSpecies

Literature, links & citation

Citations
  1. 1967Aristarain, L. F., Hurlbut, C. S., Jr,, (1967) Ameghinite, Na2O·3B2O3·4H2O, a. new borate from Argentina. American Mineralogist, 52 (7-8) 935-945
  2. 1975Dal Negro, Alberto Alberto, Pozas, Jose M., Ungaretti, Luciano (1975) The crystal structure of ameghinite. American Mineralogist, 60 (9-10) 879-883
  3. 2005(2005) Ameghinite. Handbook of Mineralogy. Mineralogical Society of America
  4. 2012Frost, Ray L., Xi, Yunfei (2012) Raman spectroscopy of the borate mineral ameghinite NaB3O3(OH)4. Spectrochimica Acta Part A: Molecular and Biomolecular Spectroscopy, 96. 89-94 doi:10.1016/j.saa.2012.04.087DOI: 10.1016/j.saa.2012.04.087
