Ammoniolasalite

[(NH4)2Mg2(H2O)20] · [V10O28]
IMA status
  • Approved
IMA symbol
Alas
Also known as
  • Ammoniolasaliet
  • Ammoniolasalitt
  • IMA2017-094

Where it forms, where it's found

Geological setting

Sandstone uranium and vanadium occurrence

Type locality
Burro Mine
  1. San Miguel County
  2. Colorado
  3. USA

38.0451°, -108.8896°

3recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789101/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Bright orange to orange-yellow
Streak
Light orange
Tenacity
brittle
Cleavage
None Observed
Fracture
Conchoidal
Density
2.28 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 31°
Refractive index
1.74 – 1.771
Surface relief
High
Principal indices
nα 1.740 · nβ 1.769 · nγ 1.771
Pleochroism
Visible

X yellow, Y yellow orange, Z orange X , Y , Z

Dispersion
Dispersion is very strong, r > v
UV response
does not exhibit fluorescence in long- or short-wave ultraviolet light
Notes

Y = b, Z Λ a = 38° in obtuse b.

Michel-Lévy diagramhighlighted lineδ = 0.0310
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]310 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation310 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/c
Cell parameters
a = 24.478(3) Å · b = 10.9413(4) Å · c = 17.551(1) Å
Cell angles
β = 17.551(7) °
Ratio a:b:c
1 : 0.447 : 0.717
Z
4
Morphology

Short prismatic (on [10_1])to equant crystals, often exhibiting stepped or skeletal faces. Forms include (001), (110), (101), (111), (111), (201), and (311).

Type-locality form

occurs as crusts on montroseite- and corvusite-bearing sandstone

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen4815.999767.952
54.76%
23VVanadiumVanadium1050.942509.420
36.32%
12MgMagnesiumMagnesium224.30548.610
3.47%
1HHydrogenHydrogen481.00848.384
3.45%
7NNitrogenNitrogen214.00728.014
2.00%
Total1402.380100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Ammoniolasaliet
  • Ammoniolasalitt
  • IMA2017-094

In other languages

German
Ammoniolasalit · IMA 2017-094
Italian
Ammoniolasalite

Classification

Strunz
10th ed.

4.HC

  • 4OxidesClass
  • 4.HV[5,6] VanadatesDivision
  • 4.HC[6]-SorovanadatesGroup
  • 4.HCAmmoniolasaliteSpecies

Group, growth & confusion

In the same group
1 members

Literature, links & citation

Citations
  1. 2018Kampf, Anthony R., Nash, Barbara P., Adams, Paul M., Marty, Joe, Hughes, John M. (2018) Ammoniolasalite, [(NH4)2Mg2(H2O)20][V10O28], a new decavanadate species from the Burro Mine, Slick Rock District, Colorado. The Canadian Mineralogist, 56 (6) 859-869 doi:10.3749/canmin.1800051 DOI: 10.3749/canmin.1800051
  2. 2020(2020) Ammoniolasalite. Handbook of Mineralogy. Mineralogical Society of America
