Ankinovichite

NiAl4(V5+O3)2(OH)12 · 2H2O
IMA status
  • Approved
IMA symbol
Akv
IMA approved
2002
Also known as
  • Ankinovichiet
  • Ankinovichitt
  • IMA2002-063

Where it forms, where it's found

Geological setting

vugs of a vanadium-bearing slate/quartz breccia

vanadium-bearing slates

Type locality
Kurumsak V Deposit
  1. Aksumbe
  2. Sozak District
  3. Turkistan Region
  4. Kazakhstan

44.3333°, 67.6333°

2recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102.5 – 3/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
colourless to pale bluish green
Streak
white
Tenacity
brittle
Cleavage
Perfect

on (010)

Density
2.48 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 84 – 88° · 2V calc = 86°
Refractive index
1.653 – 1.706
Surface relief
High
Principal indices
nα 1.653 · nβ 1.677 · nγ 1.706
Pleochroism
Non-pleochroic
Dispersion
strong v > r
UV response
none
Michel-Lévy diagramhighlighted lineδ = 0.0530
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]530 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation530 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Cell parameters
a = 17.81 Å · b = 5.123 Å · c = 8.866 Å
Cell angles
β = 92.14 °
Ratio a:b:c
1 : 0.288 : 0.498
Z
2
Morphology

elongated tabular crystals with a six-sided shape

Twinning

common

Type-locality form

crusts of tabular crystals to 0.2 mm and V-shaped twins to 0.5 mm

Comment

Space Group: P21/n

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2015.999319.980
52.92%
13AlAluminiumAluminium426.982107.928
17.85%
23VVanadiumVanadium250.942101.884
16.85%
28NiNickelNickel158.69358.693
9.71%
1HHydrogenHydrogen161.00816.128
2.67%
Total604.613100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Ankinovichiet
  • Ankinovichitt
  • IMA2002-063

In other languages

German
Ankinovichit · IMA 2002-063
Italian
Ankinovichite

Classification

Strunz
10th ed.

8.FE.05

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.FPolyphosphates, Polyarsenates, [4]-PolyvanadatesDivision
  • 8.FEIno-[4]-vanadatesGroup
  • 8.FE.05AnkinovichiteSpecies

Literature, links & citation

Citations
  1. (revised 2013) http://www.handbookofmineralogy.com/pdfs/ankinovichite.pdf (for optical data)
  2. 2004Karpenko, V.V., Pautov, L.A., Sokolova, E., Hawthorne, F.C., Agakhanov, A.A., Dkaya, T.V., Bekenova, G.K. (2004) Ankinovichite, nickel analogue of alvanite, a new mineral from Kurumsak (Kazakhstan) and Kara-Chagyr (Kirgizia). Zapiski Vserossiyskogo Mineralogicheskogo Obshchestva: 133(2): 59-68 (in Russian with English abstract).
  3. 2004Lapis (2004): 29(9): 40.
  4. 2013(2013) Ankinovichite. Handbook of Mineralogy. Mineralogical Society of America
