Anthoinite

AlWO3(OH)3
IMA status
  • Approved
  • Grandfathered
IMA symbol
Atn
Also known as
  • Anthoiniet
  • Anthoinitt

Where it forms, where it's found

Geological setting

Sn-W placers, W-bearing quartz veins

altered skarn (Kara Mine, Tasmania)

Type locality
Mt Misobo Mine
  1. Maniema
  2. DR Congo

-2.6399°, 26.5481°

13recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789101/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
White (when free of iron)
Streak
White
Cleavage
Perfect

On one direction.

Density
4.78 g/cm³

Optical

Optical type
Biaxial
Surface relief
Very high
Principal indices
n 1.81 – 1.82
Birefringence
noted under high magnification
Dispersion
r > v
Notes

Measured 2V not determined.

Crystallography

Crystal system
Triclinic
Cell parameters
a = 8.196(1) Å · b = 9.187(1) Å · c = 11.316(1) Å
Cell angles
α = 92.82(1) ° · β = 94.08(1) ° · γ = 90.23(1) °
Ratio a:b:c
1 : 1.121 : 1.381
Z
8
Morphology

Crystals platy, flattened on (010). Commonly as powdery or chalky masses and as pseudomorphs after large scheelite crystals.

Type-locality form

powdery to chalky masses, and pseudomorphs after large scheelite crystals; as platy crystals to a few mm

Comment

Space-group setting I-1.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
74WTungstenTungsten1183.840183.840
59.33%
8OOxygenOxygen615.99995.994
30.98%
13AlAluminiumAluminium126.98226.982
8.71%
1HHydrogenHydrogen31.0083.024
0.98%
Total309.840100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Anthoiniet
  • Anthoinitt

In other languages

French
Anthoinite
German
Anthoinit
Italian
Anthoinite
Chinese
水钨铝矿

Classification

Strunz
10th ed.

7.GB.35

  • 7SulfatesClass
  • 7.GMolybdates, Wolframates and NiobatesDivision
  • 7.GBWith additional anions and/or H2OGroup
  • 7.GB.35AnthoiniteSpecies
Dana
8th ed.

48.03.03.01

  • 48Anhydrous Molybdates and TungstatesClass
  • 48.03Basic Anhydrous Molybdates and TungstatesType
  • 48.03.03— unnamed intermediate level —Group
  • 48.03.03.01AnthoiniteSpecies
CIM

27.4.4

  • 27Sulphites, Chromates, Molybdates and TungstatesClass
  • 27.4TungstatesGroup
  • 27.4.4AnthoiniteSpecies

Literature, links & citation

Citations
  1. 1947Varlamoff, N. (1947) Anthoinite, nouveau tungstate hydraté d'alumine. Annales de la Société géologique de Belgique, Liége, Bulletin: 70: B153.
  2. 1948Fleischer, M. (1948) New mineral names. American Mineralogist, 33 (5-6). 384-386
  3. 1951Palache, Charles; Berman, Harry; Frondel, Clifford (1951) The System of Mineralogy (7th ed.) Vol. 2 - Halides, Nitrates, Borates, Carbonates, Sulfates, Phosphates, Arsenates, Tungstates, Molybdates, Etc. John Wiley and Sons.
  4. 1957Niggli, E., Jäger, E. (1957) Untersuchungen an Anthoinit. Neues Jahrbuch für Mineralogie, Abhandlungen: 91: 35-40. [in German]
  5. 1958Fleischer, M. (1958) New Mineral Names. American Mineralogist, 43 (3-4). 378-387
