Antipinite

KNa3Cu2(C2O4)4
IMA status
  • Approved
IMA symbol
Atp
IMA approved
2014
Also known as
  • Antipiniet
  • Antipinitt
  • IMA2014-027

Where it forms, where it's found

Geological setting

Guano deposit on chalcopyrite bearing gabbro

Type locality
Pabellón de Pica
  1. Chanabaya
  2. Iquique
  3. Iquique Province
  4. Tarapacá
  5. Chile

-20.9089°, -70.1381°

3recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Blue

pale blue, almost white

Tenacity
brittle
Cleavage
Imperfect/Fair

in three directions

Density
2.53 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 75° · 2V calc = 82°
Refractive index
1.432 – 1.698
Surface relief
Moderate
Principal indices
nα 1.432 · nβ 1.530 · nγ 1.698
Pleochroism
Strong

blue on Z, light blue on Y, colourless on X;

Bireflectance
strong, r < v
UV response
none
Michel-Lévy diagramhighlighted lineδ = 0.2660
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]2660 nm5th order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation2660 nm
Order5th order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
P-1
Cell parameters
a = 7.1574(5) Å · b = 10.7099(8) Å · c = 11.1320(8) Å
Cell angles
α = 113.093(1) ° · β = 101.294(1) ° · γ = 90.335(1) °
Ratio a:b:c
1 : 1.496 : 1.555
Unit cell volume
766.51 ų
Z
2
Morphology

Imperfect, short prismatic crystals up to 0.1 mm × 0.1 mm × 0.15 mm in size; in clusters and random aggregates.

Type-locality form

Antipinite forms imperfect, isometric and short prismatic crystals up to 0.1 mm × 0.1 mm × 0.15mm in size, as well as their random aggregates up to 0.6mm across

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1615.999255.984
43.59%
29CuCopperCopper263.546127.092
21.64%
6CCarbonCarbon812.01196.088
16.36%
11NaSodiumSodium322.99068.970
11.75%
19KPotassiumPotassium139.09839.098
6.66%
Total587.232100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Antipiniet
  • Antipinitt
  • IMA2014-027

In other languages

German
Antipinit · IMA 2014-027
Italian
antipinite

Classification

Strunz
10th ed.

10.00

  • 10Organic CompoundsClass
  • 10.0— unnamed intermediate level —Division
  • 10.00— unnamed intermediate level —Group
  • 10.00AntipiniteSpecies

Literature, links & citation

Citations
  1. 2014Williams, P. A., Hatert, F., Pasero, M., Mills, S. J. (2014) New minerals and nomenclature modifications approved in 2014, CNMNC Newsletter No 21. Mineralogical Magazine, 78 (4) 797-804 doi:10.1180/minmag.2014.078.4.03DOI: 10.1180/minmag.2014.078.4.03
  2. 2015Chukanov, Nikita V., Aksenov, Sergey M., Rastsvetaeva, Ramiza K., Lyssenko, Konstantin A., Belakovskiy, Dmitriy I., Färber, Gunnar, Möhn, Gerhard, Van, Konstantin V. (2015) Antipinite, KNa3Cu2(C2O4)4, a new mineral species from a guano deposit at Pabellón de Pica, Chile. Mineralogical Magazine, 79 (5) 1111-1121 doi:10.1180/minmag.2015.079.5.07 DOI: 10.1180/minmag.2015.079.5.07
  3. 2016(2016) Antipinite. Handbook of Mineralogy. Mineralogical Society of America
  4. 2016Cámara, Fernando; Gagne, Olivier C.; Uvarova, Yulia; Belakovskiy, Dmitriy I. (2016) New mineral names. American Mineralogist, 101 (9). 2123-2131 doi:10.2138/am-2016-nmn101916DOI: 10.2138/am-2016-nmn101916
  5. 2018Piro, Oscar Enrique, Baran, Enrique José (2018) Crystal chemistry of organic minerals – salts of organic acids: the synthetic approach. Crystallography Reviews, 24 (3) 149-175 doi:10.1080/0889311x.2018.1445239DOI: 10.1080/0889311x.2018.1445239
