Apuanite

(Fe2+Fe3+2)(Fe3+2Sb3+4)O12S
IMA status
  • Approved
IMA symbol
Apu
Discovered
1979
Also known as
  • Apuaniet
  • Apuanitt
  • IMA1978-069

Where it forms, where it's found

Geological setting

In an iron deposit, in baryte; formed by low-grade metamorphic processes at the contact between phyllites and dolostones.

Type locality
Buca della Vena Mine
  1. Pontestazzemese
  2. Stazzema
  3. Lucca Province
  4. Tuscany
  5. Italy

43.9986°, 10.2944°

1recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104 – 5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Black
Cleavage
Perfect

on (110)

Density
5.33 g/cm³

Optical

Optical type
Uniaxial
Reflectance R%
(19.1, 20.8) 470 nm, (21.9, 19.6) 546 nm, (21.6, 18.4) 589 nm, (19.6, 16.9) 650 nm
Reflected-light panel
20.6 %anisotropic · dual curve
Specimen sRGB 168, 118, 59
White reference100 % reflector under same lamp
R₁ R₂
Mode

Crystallography

Crystal system
Tetragonal
Space group
#187
Cell parameters
a = 8.372 Å · c = 17.974 Å
Z
4
Morphology

Prismatic crystals, thick-tabular on (001) and bounded by (110), (112) and (114).

Type-locality form

Commonly massive; rarely as prismatic, thick tabular crystals.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
51SbAntimonyAntimony4121.760487.040
49.18%
26FeIronIron555.845279.225
28.19%
8OOxygenOxygen1215.999191.988
19.39%
16SSulfurSulfur132.06032.060
3.24%
Total990.313100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Apuaniet
  • Apuanitt
  • IMA1978-069

In other languages

German
Apuanit · IMA 1978-069
Italian
Apuanite

Classification

Strunz
10th ed.

4.JA.25

  • 4OxidesClass
  • 4.JArsenites, antimonites, bismuthites, sulfites, selenites, tellurites; iodatesDivision
  • 4.JAArsenites, antimonites, bismuthites; without additional anions, without H2OGroup
  • 4.JA.25ApuaniteSpecies
Dana
8th ed.

45.01.09.01

  • 45Acid and Normal Antimonites and ArsenitesClass
  • 45.01MiscellaneousType
  • 45.01.09— unnamed intermediate level —Group
  • 45.01.09.01ApuaniteSpecies
CIM

4.10

  • 4OxysulphidesClass
  • 4.10— unnamed intermediate level —Group
  • 4.10ApuaniteSpecies

Group, growth & confusion

Often grow together
1 mineral

Literature, links & citation

Citations
  1. 1979Mellini, Marcello, Merlino, Stefano, Orlandi, Paolo (1979) Versiliaite and apuanite, two new minerals from the Apuan Alps, Italy. American Mineralogist, 64 (11-12) 1230-1234
  2. 1979Mellini, Marcello, Merlino, Stefano (1979) Versiliaite and apuanite: derivative structures related to schafarzikite. American Mineralogist, 64 (11-12) 1235-1242
  3. 1981Mellini, Marcello, Amouric, Marc, Baronnet, Alain, Mercuriot, Genevieve (1981) Microstructures and nonstoichiometry in schafarzikite-like minerals. American Mineralogist, 66 (9-10) 1073-1079
  4. 1997Anthony, J. W. et al. (1997) Handbook of Mineralogy, Vol. 3, 19.
  5. 2005(2005) Apuanite. Handbook of Mineralogy. Mineralogical Society of America
