Ashcroftine-(Y)

K5Na5Y12Si28O70(OH)2(CO3)8 · 8H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Acf-Y
Discovered
1924
Also known as
  • Kalithomsonite

Where it forms, where it's found

Type locality
Narssârssuk pegmatite
  1. Narsaarsuk Plateau
  2. Igaliku
  3. Kujalleq
  4. Greenland

61.0331°, -45.3778°

4recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Pink
Streak
White
Tenacity
brittle
Cleavage
Perfect

(100), also (001) good

Fracture
Irregular/Uneven
Density
2.61 g/cm³

Optical

Optical type
Uniaxial (+)
Refractive index
1.536 – 1.549
Surface relief
Moderate
Principal indices
nω 1.536 – 1.537 · nε 1.545 – 1.549
Birefringence
0.010
Pleochroism
Non-pleochroic
Extinction
Parallel
UV response
Not fluorescent.
Michel-Lévy diagramhighlighted lineδ = 0.0100
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]100 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation100 nm
Order1st order
XPL colour

Crystallography

Crystal system
Tetragonal
Space group
#176
Cell parameters
a = 23.99 Å · c = 17.51 Å
Z
2
Morphology

Acicular, rod-like

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen10415.9991663.896
42.21%
39YYttriumYttrium1288.9061066.872
27.06%
14SiSiliconSilicon2828.085786.380
19.95%
19KPotassiumPotassium539.098195.490
4.96%
11NaSodiumSodium522.990114.950
2.92%
6CCarbonCarbon812.01196.088
2.44%
1HHydrogenHydrogen181.00818.144
0.46%
Total3941.820100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Kalithomsonite

In other languages

German
Ashcroftin-(Y)
Italian
Ashcroftina- · Ashcroftina-(Y) · Ashcroftine-(Y)
Chinese
硅碱钙钇石
Russian
Ашкрофтин

Classification

Strunz
10th ed.

9.DN.15

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DNInosilicates with 6-periodic double chainsGroup
  • 9.DN.15Ashcroftine-(Y)Species
Dana
8th ed.

70.03.01.01

  • 70Inosilicates Column or Tube StructuresClass
  • 70.03Column or Tube Structures with balo-silicatesType
  • 70.03.01— unnamed intermediate level —Group
  • 70.03.01.01Ashcroftine-(Y)Species
CIM

14.8.9

  • 14Silicates not Containing AluminumClass
  • 14.8Silicates of Group III metals other than AlGroup
  • 14.8.9Ashcroftine-(Y)Species

Literature, links & citation

Citations
  1. 1933Hey, Max H., Bannister, F. A. (1933) Studies on the zeolites. Part IV. Ashcroftine (kalithomsonite of S. G. Gordon) Mineralogical Magazine and Journal of the Mineralogical Society, 23 (140) 305-308 doi:10.1180/minmag.1933.023.140.02 DOI: 10.1180/minmag.1933.023.140.02
  2. 1969Moore, P. B., Bennett, J. M., Louisnathan, S. J. (1969) Ashcroftine is not a zeolite!. Mineralogical Magazine, 37 (288) 515-517 doi:10.1180/minmag.1969.037.288.12 DOI: 10.1180/minmag.1969.037.288.12
  3. 1970Fleischer, M., Nickel, E.H. (1970) New mineral names. American Mineralogist: 55: 1810-1818.
  4. 1987Nickel, Ernest H., Mandarino, Joseph A. (1987) Procedures involving the IMA Commission on New Minerals and Mineral Names and guidelines on mineral nomenclature. American Mineralogist, 72 (9-10) 1031-1042
  5. 1987Moore, Paul Brian, Gupta, Pradip K Sen, Schlemper, Elmer O., Merlino, Stefano (1987) Ashcroftine, ca. K10Na10(Y,Ca)24(OH)4(CO3)16(Si56O140)·16H2O, a structure with enormous polyanions. American Mineralogist, 72 (11-12) 1176-1189
