Asisite

Pb7SiO8Cl2
IMA status
  • Approved
IMA symbol
Ass
Discovered
1988
Also known as
  • Asisitt
  • IMA1987-003

Where it forms, where it's found

Geological setting

Manganese silicate lens.

Type locality
Kombat Mine
  1. Kombat
  2. Otavi Constituency
  3. Otjozondjupa Region
  4. Namibia

-19.7081°, 17.7033°

4recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789103.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Yellow to yellow-green · red
Streak
Light yellow to white
Cleavage
Perfect

(001)

Density
8.041 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
2.32 – 2.39
Surface relief
Very high
Principal indices
nω 2.39 · nε 2.32
Pleochroism
Non-pleochroic
Optical colour
Gray
Anisotropism
Not noticeable in air, only weakly so in oil, rotation tints of gray
Bireflectance
Not perceptible, except at grain boundaries
Internal reflections
Abundant uncolored reflections in plane-polarized light, brilliant pale greenish yellow between crossed polars
Tropism
Anisotropic
Reflectance R%
(20.2, 20.7) 400, (17.9, 18.9) 450, (16.9, 17.9) 500, (16.2, 17.15) 550, (15.7, 16.7) 600, (15.35, 16.3) 650, (15.1, 16.1) 700
Reflected-light panel
16.8 %anisotropic · dual curve
Specimen sRGB 147, 104, 60
White reference100 % reflector under same lamp
R₁ R₂
Mode
Bireflectance
Not perceptible, except at grain boundaries
Anisotropism
Not noticeable in air, only weakly so in oil, rotation tints of gray
Reflected colour
Gray
Internal reflections
Abundant uncolored reflections in plane-polarized light, brilliant pale greenish yellow between crossed polars

Crystallography

Crystal system
Tetragonal
Space group
#176
Cell parameters
a = 3.897(2) Å · c = 22.81(2) Å
Z
1
Morphology

Tabular on (001).

Type-locality form

Yellow to greenish-yellow, 0.5 mm, platy crystals.

Comment

Only subcell (but strongly dominant); real cell has tetragonal cell parameters ~14 and ~23 A (Welch, 2004)

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead7207.2001450.400
86.47%
8OOxygenOxygen815.999127.992
7.63%
17ClChlorineChlorine235.45070.900
4.23%
14SiSiliconSilicon128.08528.085
1.67%
Total1677.377100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Asisitt
  • IMA1987-003

In other languages

German
Asisit · IMA 1987-003
Spanish
Asisita
Italian
Asisite
Portuguese
Asisita · IMA1987-003

Classification

Strunz
10th ed.

3.DB.40

  • 3HalidesClass
  • 3.DOxyhalides, hydroxyhalides and related double halidesDivision
  • 3.DBWith Pb, Cu, etc.Group
  • 3.DB.40AsisiteSpecies
Dana
8th ed.

10.02.07.01

  • 10Oxyhalides and HydroxyhalidesClass
  • 10.02A(O,OH)XqType
  • 10.02.07— unnamed intermediate level —Group
  • 10.02.07.01AsisiteSpecies
CIM

17.3.9

  • 17Silicates Containing other AnionsClass
  • 17.3Silicates with chloride (including aluminosilicates)Group
  • 17.3.9AsisiteSpecies

Literature, links & citation

Citations
  1. 1988Rouse, Roland C., Peacor, Donald R., Dunn, Pete J., Criddle, Alan J., Stanley, Chris J., Innes, John (1988) Asisite, a silicon-bearing lead oxychloride from the Kombat mine, South West Africa (Namibia) American Mineralogist, 73 (5-6) 643-650
  2. 2004Welch, M. D. (2004) Pb-Si ordering in sheet-oxychloride minerals: the super-structure of asisite, nominally Pb7SiO8Cl2. Mineralogical Magazine, 68 (2) 247-254 doi:10.1180/0026461046820185DOI: 10.1180/0026461046820185
  3. 2013(2013) Asisite. Handbook of Mineralogy. Mineralogical Society of America
