Aspedamite

12(Fe3+,Fe2+)3Nb4[Th(Nb,Fe3+)12O42][(H2O),(OH)]12
IMA status
  • Approved
IMA symbol
Apd
IMA approved
2011
Also known as
  • Aspedamiet
  • Aspedamitt
  • IMA2011-056

Where it forms, where it's found

Geological setting

Granite pegmatite

Type locality
Herrebøkasa
  1. Aspedammen
  2. Idd
  3. Halden
  4. Østfold
  5. Norway

59.0753°, 11.4764°

1recorded occurrences
Source · OpenStreetMap

Radioactivity

Physical

Hardness
123456789103 – 4/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Colour
Brownish orange to deep red
Streak
Very pale orange
Tenacity
brittle
Cleavage
None Observed
Density
4.070 g/cm³

Optical

Optical type
Isotropic
Surface relief
Very high
Principal indices
n 2.084
UV response
None
Notes

Refractive index is calculated.

Isotropy testPPL ↔ XPL diagnostic
PPL intrinsic colour; no change on stage rotation
XPL extinct at every orientation
Single index
n = 2.084

Crystallography

Crystal system
Isometric
Space group
#203
Cell parameters
a = 12.9078(6) Å
Unit cell volume
2150.6 ų
Z
2
Morphology

Dominant forms: the dodecahedron (110) modified by the cube (100)

Twinning

None observed

Parting
None observed
Type-locality form

Small to 50 micron, euhedral crystals of dodecahedra and cubes perched on a white mat of an Al-Nb-Fe-Ti-Ca-K-bearing silicate on a partly 12 x 12 x 6 mm large monazite crystal.

Crystal structure

Synonyms

  • Aspedamiet
  • Aspedamitt
  • IMA2011-056

In other languages

German
Aspedamit · IMA 2011-056

Classification

Strunz
10th ed.

4.FN

  • 4OxidesClass
  • 4.FHydroxides (without V or U)Division
  • 4.FNHydroxides with H2O±(OH); frameworks of corner and/or face-sharing octahedraGroup
  • 4.FNAspedamiteSpecies

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 2011Williams, P. A., Hatert, F., Pasero, M., Mills, S. J. (2011) New minerals and nomenclature modifications approved in 2011. CNMNC Newsletter No 11. Mineralogical Magazine, 75 (6) 2887-2893 doi:10.1180/minmag.2011.075.6.2887 DOI: 10.1180/minmag.2011.075.6.2887
  2. 2012Cooper, M. A., Abdu, Y. A., Ball, N. A., Cerny, P., Hawthorne, F. C., Kristiansen, R. (2012) Aspedamite, ideally ◻12(Fe3+,Fe2+)3Nb4[Th(Nb,Fe3+)12O42]{(H2O),(OH)}12, a new heteropolyniobate mineral species from the Herrebøkasa Quarry, Aspedammen, Østfold, southern Norway: description and crystal structure. The Canadian Mineralogist, 50 (4) 793-894 doi:10.3749/canmin.50.4.793 DOI: 10.3749/canmin.50.4.793
  3. 2014(2014) Aspedamite. Handbook of Mineralogy. Mineralogical Society of America
