Atokite

Pd3Sn
IMA status
  • Approved
IMA symbol
Ato
Discovered
1975
Also known as
  • Atokiet
  • Atokitt
  • IMA1974-041

Where it forms, where it's found

Geological setting

As very sparse grains in concentrates of ore.

Type locality
Atok Mine
  1. Fetakgomo Tubatse Local Municipality
  2. Sekhukhune District Municipality
  3. Limpopo
  4. South Africa

-24.2972°, 29.8792°

39recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Metallic
Transparency
Opaque
Colour
Light cream

in reflected light

Density
14.19 g/cm³

Optical

Optical type
Isotropic
Pleochroism
Weak
Optical colour
light cream
Anisotropism
Slight, due to strain
Tropism
Anisotropic
Reflectance R%
(57.4, 60.8) 480, (59.2, 65.1) 546, (60.4, 63.5) 589, (62.2, 65.8) 656
Reflected-light panel
59.8 %anisotropic · dual curve
Specimen sRGB 255, 187, 102
White reference100 % reflector under same lamp
R₁ R₂
Mode
Anisotropism
Slight, due to strain
Reflected colour
light cream

Crystallography

Crystal system
Isometric
Space group
Fm3m
Cell parameters
a = 3.991 Å
Z
4
Morphology

Small grains less than 100 microns.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
46PdPalladiumPalladium3106.420319.260
72.90%
50SnTinTin1118.710118.710
27.10%
Total437.970100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Atokiet
  • Atokitt
  • IMA1974-041

In other languages

German
Atokit · IMA 1974-041
Italian
Atokite

Classification

Strunz
10th ed.

1.AG.10

  • 1ElementsClass
  • 1.AMetals and Intermetallic AlloysDivision
  • 1.AGPGE-metal alloysGroup
  • 1.AG.10AtokiteSpecies
Dana
8th ed.

01.02.05.03

  • 01Native Elements and AlloysClass
  • 01.02Platinum Group Metals and AlloysType
  • 01.02.05Isoferroplatinum group (Space Group Pm3m)Group
  • 01.02.05.03AtokiteSpecies
CIM

1.72

  • 1Elements and Alloys (including the arsenides, antimonides and bismuthides of Cu, Ag and Au)Class
  • 1.72— unnamed intermediate level —Group
  • 1.72AtokiteSpecies

Group, growth & confusion

Often grow together
2 minerals

Literature, links & citation

Citations
  1. 1975Mihálik, P., Hiemstra, S.A., De Villiers, J.P.R. (1975) Rustenburgite and atokite, two new platinum-group minerals from the Merensky Reef, Bushveld igneous complex. The Canadian Mineralogist: 13: 146-150.
  2. 1976(1976): American Mineralogist 61, 339-340.
  3. 2005(2005) Atokite. Handbook of Mineralogy. Mineralogical Society of America
