Bandylite

CuB(OH)4Cl
IMA status
  • Approved
  • Grandfathered
IMA symbol
Bny
Discovered
1938
Also known as
  • Bandyliet
  • Bandylit

Where it forms, where it's found

Geological setting

In a leached zone above massive iron sulphates

Type locality
Queténa Mine (Queténa Prospect)
  1. Toki Cu deposit (Toki Cluster)
  2. Chuquicamata District
  3. Calama
  4. El Loa Province
  5. Antofagasta
  6. Chile

-22.3701°, -69.0353°

3recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Transparent
Colour
Deep blue with greenish portions · cendre blue to Italian blue · becoming greener with atacamite inclusions · blue in transmitted light.
Streak
Pale blue
Tenacity
elastic
Cleavage
Perfect

on (001).

Density
2.81 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.64 – 1.692
Surface relief
High
Principal indices
nω 1.691 – 1.692 · nε 1.64 – 1.641
Pleochroism
Strong

O = Deep cendre blue E = Light greenish yellow

Michel-Lévy diagramhighlighted lineδ = 0.0510
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]510 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation510 nm
Order1st order
XPL colour

Crystallography

Crystal system
Tetragonal
Space group
#185
Cell parameters
a = 6.19 Å · c = 5.61 Å
Z
2
Morphology

Crystals typically tabular on (001) or equant with large (001), (201), and (110), having quadrangular terraces on (001). dominant forms are (001), (111), (201) and (110). Occurs as subparallel clusters forming lichen-like groups with the individual crystals flattened on the base or on a pyramidal face.

Type-locality form

Tabular or pyramidal crystals to 5 mm and almost lichen-like radial clusters in joints in the rock.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen415.99963.996
35.99%
29CuCopperCopper163.54663.546
35.73%
17ClChlorineChlorine135.45035.450
19.93%
5BBoronBoron110.81010.810
6.08%
1HHydrogenHydrogen41.0084.032
2.27%
Total177.834100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Fe

Synonyms

  • Bandyliet
  • Bandylit

In other languages

German
Bandylith
Spanish
Bandylita
Italian
bandylite
Russian
Бандилит

Classification

Strunz
10th ed.

6.AC.35

  • 6BoratesClass
  • 6.AMonoboratesDivision
  • 6.ACB(O,OH)4, without and with additional anions; 1(T), 1(T)+OH, etcGroup
  • 6.AC.35BandyliteSpecies
Dana
8th ed.

25.01.04.02

  • 25Anhydrous Borates Containing Hydroxyl or HalogenClass
  • 25.01MonoboratesType
  • 25.01.04— unnamed intermediate level —Group
  • 25.01.04.02BandyliteSpecies
CIM

10.1.2

  • 10Borates with other anionsClass
  • 10.1Borates with halideGroup
  • 10.1.2BandyliteSpecies

Literature, links & citation

Citations
  1. 1938Palache, Charles, Foshag, W. F. (1938) Antofagastite and bandylite, two new copper minerals from Chile. American Mineralogist, 23 (2) 85-90
  2. 1938Bandy, Mark C. (1938) Mineralogy of three sulphate deposits of northern Chile. American Mineralogist, 23 (11) 669-760
  3. 1950Fornaseri, M. (1950) La struttura cristallina della bandylite. Periodico di Mineralogia, Roma: 157-179 (in Italian).
  4. 1951Palache, Charles; Berman, Harry; Frondel, Clifford (1951) The System of Mineralogy (7th ed.) Vol. 2 - Halides, Nitrates, Borates, Carbonates, Sulfates, Phosphates, Arsenates, Tungstates, Molybdates, Etc. John Wiley and Sons.
  5. 1951Collin, R. L. (1951) The crystal structure of bandylite, CuCl2.CuB2O4.4H2O. Acta Crystallographica, 4 (3) 204-209 doi:10.1107/s0365110x51000726DOI: 10.1107/s0365110x51000726
