Barahonaite-(Al)

(Ca,Cu,Na,Fe3+,Al)12Al2(AsO4)8(OH,Cl)x · nH2O
IMA status
  • Approved
IMA symbol
Bho-Al
IMA approved
2007
Also known as
  • Barahonaiet-(Al)
  • Barahonite-(Al)
  • IMA2006-051
  • +1 more

Where it forms, where it's found

Geological setting

An oxidation mineral occurring as coatings and within closely spaced fractures in weathered siliceous and micaceous host-rocks.

Type locality
La Reconquistada claim
  1. Pastrana
  2. Mazarrón
  3. Murcia
  4. Spain
5recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Transparency
Transparent · Translucent
Colour
Pale blue
Streak
White
Tenacity
brittle
Density
3.03 g/cm³

Optical

Optical type
Biaxial (-)
Refractive index
1.616 – 1.622
Surface relief
Moderate
Principal indices
nα 1.616 · nγ 1.622
UV response
Not fluorescent.
Notes

Interference color is grey to yellow. Presumed to be biaxial (–), analogous to the optic sign for barahonaite-(Fe). β was not determined.

Michel-Lévy diagramhighlighted lineδ = 0.0060
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]60 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation60 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#12
Cell parameters
a = 9.972 Å · b = 22.44 Å · c = 5.272 Å
Cell angles
β = 92.9 °
Ratio a:b:c
1 : 2.250 : 0.529
Morphology

Plates, commonly curved, with a maximum size of ~50 µm in diameter and thickness <1 µm.

Type-locality form

Beads, coalesced beads, and crusts of submillimetric thickness whose surfaces commonly glisten because of the presence of plates, up to 50 µm in diameter (Utah), and razor-thin, tabular, composite crystals, up to 20 µm long (Spain). The crystal units are somewhat divergent, and the texture varies from rosette to boxwork-like.

Synonyms

  • Barahonaiet-(Al)
  • Barahonite-(Al)
  • IMA2006-051
  • Unnamed (Ca Arsenate)

In other languages

German
Barahonait-(Al) · IMA 2006-051
Spanish
Barahonaíta- · Barahonaíta-(Al)
Italian
Barahonaite- · Barahonaite-(Al)

Classification

Strunz
10th ed.

8.CH.60

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.CPhosphates without additional anions, with H2ODivision
  • 8.CHWith large and medium-sized cations, RO4:H2O < 1:1Group
  • 8.CH.60Barahonaite-(Al)Species
Dana
8th ed.

40.06.04.01

  • 40Hydrated Normal Phosphates, Arsenates and VanadatesClass
  • 40.06(AB)5(XO4)4·xH2OType
  • 40.06.04— unnamed intermediate level —Group
  • 40.06.04.01Barahonaite-(Al)Species

Literature, links & citation

Citations
  1. 2008Viñals, J., Jambor, J. L., Raudsepp, M., Roberts, A. C., Grice, J. D., Kokinos, M., Wise, W. S. (2008) Barahonaite-(Al) and barahonaite-(Fe), new Ca-Cu arsenate mineral species, from Murcia Province, southeastern Spain, and Gold Hill, Utah. The Canadian Mineralogist, 46 (1) 205-217 doi:10.3749/canmin.46.1.205 DOI: 10.3749/canmin.46.1.205
  2. 2022(2022) Barahonaite-(Al). Handbook of Mineralogy. Mineralogical Society of America
