Bario-olgite

Na(Na,Sr,Ce)2Ba(PO4)2
IMA status
  • Approved
IMA symbol
Bolg
IMA approved
2005
Also known as
  • Bario-olgiet
  • IMA2003-002

Where it forms, where it's found

Geological setting

Hyeragpaitic pegmatite.

Type locality
Palitra pegmatite
  1. Karnasurt mine
  2. Karnasurt Mountain
  3. Lovozersky District
  4. Murmansk Oblast
  5. Russia
1recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104 – 4.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Light green
Streak
White
Tenacity
brittle
Cleavage
Poor/Indistinct

Imperfect on (00l) and (hk0).

Fracture
Irregular/Uneven
Density
3.986 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.623 – 1.628
Surface relief
Moderate
Principal indices
nω 1.628 · nε 1.623
UV response
Bright pink-orange in (short wave) and weak pink-red (long wave).
Michel-Lévy diagramhighlighted lineδ = 0.0050
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]50 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation50 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
#75
Cell parameters
a = 5.549 Å · c = 7.032 Å
Unit cell volume
187.5 ų
Z
1
Type-locality form

Grains up to 1.5 x 1 cm and, more rarely, pyramidal-prismatic crystals.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
58CeCeriumCerium2140.116280.232
32.90%
38SrStrontiumStrontium287.620175.240
20.58%
56BaBariumBarium1137.327137.327
16.12%
8OOxygenOxygen815.999127.992
15.03%
11NaSodiumSodium322.99068.970
8.10%
15PPhosphorusPhosphorus230.97461.948
7.27%
Total851.709100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Sr
  • La
  • Ce
  • Ca
  • K
  • Mn
  • Si

Synonyms

  • Bario-olgiet
  • IMA2003-002

In other languages

German
Bario-Olgit · IMA 2003-002
Italian
Bario-olgite

Classification

Strunz
10th ed.

8.AC.40

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.APhosphates, etc. without additional anions, without H2ODivision
  • 8.ACWith medium-sized and large cationsGroup
  • 8.AC.40Bario-olgiteSpecies
Dana
8th ed.

38.01.03.02

  • 38Anhydrous Normal Phosphates, Arsenates, and VanadatesClass
  • 38.01ABXO4Type
  • 38.01.03— unnamed intermediate level —Group
  • 38.01.03.02Bario-olgiteSpecies

Literature, links & citation

Citations
  1. 1990Sokolova, E.V., Nadezhina, T.N., and Khomyakov, A.P. (1990) The X-ray diffraction study of highly barium-enriched olgite. Vestnik MGU, ser. Geology N1: 87-91 (in Russian).
  2. 2004Pekov, I.V., Chukanov, N.V., Kulikova, I.M., Zubkova, N.V., Krotova, O.D., Sorokina, N.I., Pushcharovsky, D.Yu. (2004): New mineral bario-olgite, Ba(Na,Sr,REE)2Na[PO4]2, and its crystal structure. Zapiski Vserossiyskogo Mineralogicheskogo Obshchestva: 133(1): 41-49.
  3. 2005Sokolova, E., Hawthorne, F. C., Khomyakov, A. P. (2005) Refinement of the crystal structure and revision of the chemical formula of olgite: (Ba,Sr) (Na,Sr,REE)2Na[PO4]2. The Canadian Mineralogist, 43 (5) 1521-1526 doi:10.2113/gscanmin.43.5.1521 DOI: 10.2113/gscanmin.43.5.1521
  4. 2021(2021) Bario-olgite. Handbook of Mineralogy. Mineralogical Society of America
