Bartonite

K6Fe20S26S
IMA status
  • Approved
IMA symbol
Btn
Discovered
1978
Also known as
  • Bartoniet
  • IMA1977-039

Where it forms, where it's found

Geological setting

Alkalic diatreme

Type locality
Coyote Peak
  1. Humboldt County
  2. California
  3. USA

41.1333°, -123.8589°

11recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Submetallic
Transparency
Opaque
Colour
Blackish-brown
Streak
Black
Cleavage
Distinct/Good

Distinct on (112)

Fracture
Conchoidal
Density
3.305 g/cm³

Optical

Pleochroism
Weak
Optical colour
Yellowish green-gray to yellowish green-brown
Tropism
Anisotropic
Reflectance R%
(21.7, 18.3) 400, (16.7, 14.4) 420, (17.7, 17.2) 440, (18.4, 18.6) 460, (19.4, 19.5) 480, (19.7, 20.6) 500, (20.3, 21.4) 520, (20.9, 21.8) 540, (21.9, 22.7) 560, (22.7, 23.2) 580, (23.4, 23.7) 600, (23.9, 24.3) 620, (24.7, 25.1) 640, (25.0, 25.5) 660, (25.2, 26.1) 680, (26.4, 26.5) 700
Reflected-light panel
21.8 %anisotropic · dual curve
Specimen sRGB 180, 117, 56
White reference100 % reflector under same lamp
R₁ R₂
Mode
Reflected colour
Yellowish green-gray to yellowish green-brown

Crystallography

Crystal system
Tetragonal
Space group
I4/mmm
Cell parameters
a = 10.424(1) Å · c = 20.626(1) Å
Z
2
Morphology

Anhedral masses in pyrrhotite to 5x50 microns.

Type-locality form

Anhedral masses, intergrown with pyrrhotite; rare elongated single crystals, to 50 μm long.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
26FeIronIron2055.8451116.900
50.38%
16SSulfurSulfur2732.060865.620
39.04%
19KPotassiumPotassium639.098234.588
10.58%
Total2217.108100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Na
  • Cu
  • Ni
  • Co
  • Cl

Synonyms

  • Bartoniet
  • IMA1977-039

In other languages

German
Bartonit · IMA 1977-039
Italian
Bartonite
Chinese
巴硫铁钾矿

Classification

Strunz
10th ed.

2.FC.10

  • 2Sulfides and SulfosaltsClass
  • 2.FSulfides of arsenic, alkalies; sulfides with halide, oxide, hydroxide, H2ODivision
  • 2.FCWith Cl, Br, I (halide-sulfides)Group
  • 2.FC.10BartoniteSpecies
Dana
8th ed.

02.09.19.01

  • 02SulfidesClass
  • 02.09AmBnXp, with (m+n):p = 1:1Type
  • 02.09.19Bartonite GroupGroup
  • 02.09.19.01BartoniteSpecies
CIM

3.0.5

  • 3Sulphides, Selenides, Tellurides, Arsenides and Bismuthides (except the arsenides, antimonides and bismuthides of Cu, Ag and Au, which are included in Section 1)Class
  • 3.0Sulphides etc. of the alkalisGroup
  • 3.0.5BartoniteSpecies

Literature, links & citation

Citations
  1. 1973Fleischer, Michael (1973) New mineral names. American Mineralogist, 58 (5-6). 560-562
  2. 1978CZAMANSKE, G; LANPHERE, M; ERD, R; BLAKEJR, M (1978) Age measurements of potassium-bearing sulfide minerals by the 40Ar/39Ar technique. Earth and Planetary Science Letters, 40 (1). 107-110 doi:10.1016/0012-821x(78)90079-1DOI: 10.1016/0012-821x(78)90079-1
  3. 1979Fleischer, Michael, Chao, George Y., Pabst, and Adolf (1979) New Mineral Names. American Mineralogist, 64 (1-2) 241-245
  4. 1981Czamanske, Gerald K., Erd, Richard C., Leonard, B. F., Clark, Joan R. (1981) Bartonite, a new potassium iron sulfide mineral. American Mineralogist, 66 (3-4) 369-375
  5. 1981Evans, Howard T., Clark, Joan R (1981) The crystal structure of bartonite, a potassium iron sulfide, and its relationship to pentlandite and djerfisherite. American Mineralogist, 66 (3-4) 376-384
