Barysilite

Pb8Mn(Si2O7)3
IMA status
  • Approved
  • Grandfathered
IMA symbol
Bsl
Discovered
1888
Also known as
  • Barisilite
  • Barysiliet
  • Barysilita

Where it forms, where it's found

Geological setting

Iron ores.

Type locality
Harstigen Mine
  1. Pajsberg
  2. Persberg ore district
  3. Filipstad
  4. Värmland County
  5. Sweden

59.7853°, 14.3139°

11recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789103/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
White · pink to colorless · tarnishes on exposure
Tenacity
brittle
Cleavage
Perfect

(0001)

Fracture
Irregular/Uneven
Density
6.55 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
2.015 – 2.07
Surface relief
Very high
Principal indices
nω 2.033 – 2.07 · nε 2.015 – 2.05
Michel-Lévy diagramhighlighted lineδ = 0.0190
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]190 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation190 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
R-3c
Cell parameters
a = 9.821 Å · c = 38.35 Å
Z
6
Morphology

As platy, subparallel crystals in lamellar and ball-like aggregates, to 3 mm; granular, massive.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead8207.2001657.600
74.77%
8OOxygenOxygen2115.999335.979
15.15%
14SiSiliconSilicon628.085168.510
7.60%
25MnManganeseManganese154.93854.938
2.48%
Total2217.027100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Al
  • Fe
  • Zn
  • Mg
  • Ca

Synonyms

  • Barisilite
  • Barysiliet
  • Barysilita

In other languages

German
Barysilit
Italian
Barysilite

Classification

Strunz
10th ed.

9.BC.20

  • 9SilicatesClass
  • 9.BSorosilicatesDivision
  • 9.BCSi2O7 groups, without non-tetrahedral anions; cations in octahedral [6] and greater coordinationGroup
  • 9.BC.20BarysiliteSpecies
Dana
8th ed.

55.02.03.01

  • 55Sorosilicates Si2o7 Groups, Generally with No Additional AnionsClass
  • 55.02Si2O7 Groups, Generally with no Additional Anions with cations in [6] coordinationType
  • 55.02.03— unnamed intermediate level —Group
  • 55.02.03.01BarysiliteSpecies
CIM

14.13.8

  • 14Silicates not Containing AluminumClass
  • 14.13Silicates of PbGroup
  • 14.13.8BarysiliteSpecies

Literature, links & citation

Citations
  1. 1888Sjögren, Ant., Lundström, C.H. (1888) Om Barysil, ett förr ej uppmärksammat mineral från Harstigsgrufvan [About Barysil, a previously unnoticed mineral from Harstigsgrufvan]. Öfversigt af Kongl. vetenskaps-akademiens förhandlingar, 45. 7-10
  2. 1926Shannon, Earl V., Berman, H. (1926) Barysilite from Franklin Furnace, N. J. American Mineralogist, 11 (5). 130-132
  3. 1964Glasser, F. P. (1964) New data on barysilite. American Mineralogist, 49 (9-10) 1485-1488
  4. 1966Lajzérowicz, J. (1966) Etude par diffraction des rayons X et absorption infra-rouge de la barysilite, MnPb8,3Si2O7, et de composés isomorphes. Acta Crystallographica, 20 (3). 357-363 doi:10.1107/s0365110x66000847DOI: 10.1107/s0365110x66000847
  5. 1967Ito, Jun, Frondel, Clifford (1967) Syntheses of lead silicates: larsenite, barysilite and related phases. American Mineralogist, 52 (7-8) 1077-1084
