Belyankinite

Ca1-2(Ti,Zr,Nb)5O12 · 9H2O (?)
IMA status
  • Approved
  • Grandfathered
  • Questionable
IMA symbol
Byn
Also known as
  • Belijankinit
  • Belyankiniet

Where it forms, where it's found

Geological setting

In nepheline syenite in an alkalic massif, included in aegirine and microcline

Type locality
Medvezh'ya Berloga pegmatite (Pegmatite No. 13)
  1. Tyulbnyunuai River Valley
  2. Lovozersky District
  3. Murmansk Oblast
  4. Russia
3recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102 – 3/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous · oily · pearly.
Transparency
Opaque
Colour
White · light yellow to brownish-yellow · black when manganese-rich
Tenacity
brittle
Cleavage
Perfect

in one direction, parallel to the plates

Fracture
Irregular/Uneven
Density
2.32 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 21 – 25°
Refractive index
1.74 – 1.78
Surface relief
High
Principal indices
nα 1.74 · nβ 1.772 – 1.778 · nγ 1.775 – 1.78
Pleochroism
Visible

X = brown to dark brown, Y = light brown to yellow-brown, Z = light brown; Orientation: X = a, Y = b, Z = c

Dispersion
r > v, moderate
Isotropy testPPL ↔ XPL diagnostic
PPL intrinsic colour; no change on stage rotation
XPL extinct at every orientation

Crystallography

Crystal system
Amorphous
Morphology

In platy aggregates or massive, to 20 cm

Comment

Crystal Data: Orthorhombic or monoclinic. Point Group: n.d. Space Group: n.d. Z = n.d.

Synonyms

  • Belijankinit
  • Belyankiniet

In other languages

German
Belyankinit
Italian
Belyankinite
Chinese
锆钛钙石
Russian
Белянкинит

Classification

Strunz
10th ed.

4.FM.25

  • 4OxidesClass
  • 4.FHydroxides (without V or U)Division
  • 4.FMHydroxides with H2O +- (OH); unclassifiedGroup
  • 4.FM.25BelyankiniteSpecies
Dana
8th ed.

08.07.08.01

  • 08Multiple Oxides Containing Niobium, Tantalum or TitaniumClass
  • 08.07MiscellaneousType
  • 08.07.08Belyankinite GroupGroup
  • 08.07.08.01BelyankiniteSpecies
CIM

18.1.12

  • 18Niobates and TantalatesClass
  • 18.1Niobates and tantalates containing neither rare earths nor UGroup
  • 18.1.12BelyankiniteSpecies

Literature, links & citation

Citations
  1. 1950Gerasimovskii, V.I., Kazakova, M.E. (1950) Belyankinite - a new mineral. Doklady Akademii Nauk SSSR: 71: 925-927 (in Russian).
  2. 1952American Mineralogist (1952), 37, 882 (abstract).
  3. 1957Semenov, E.I. (1957) Oxides and hydroxides of titanium and niobium in the Lovozero alkaline massif. Trudy Institut Mineralogii, Geokhimii, Kristallokhim. Redkikh Elementov, Akademiia Nauk SSSR 1: 41-59 (in Russian). https://rruff.info/rruff_1.0/uploads/ANSSSR1_41.pdf or https://rruff.info/rruff_1.0/uploads/Trudy1_41.pdf
  4. 1958American Mineralogist (1958), 43, 1220-1221 (abstract).
  5. 1966Vlasov, K.A., Kuz'menko, M.V., Es'kova, E.M. (1966) The Lovozero alkali massif. Akademii Nauk SSSR: 390-392 (in English).
