Beyerite

CaBi2O2(CO3)2
IMA status
  • Approved
  • Grandfathered
IMA symbol
Bey
Discovered
1943
Also known as
  • Beyeriet

Where it forms, where it's found

Type locality
Schneeberg
  1. Erzgebirgskreis
  2. Saxony
  3. Germany
111recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102 – 3/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Colour
White to bright yellow · or greyish-green · grey · light yellow to colourless in transmitted light
Streak
White
Cleavage
None Observed
Fracture
Conchoidal
Density
6.56 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.97 – 2.13
Surface relief
Very high
Principal indices
nω 2.13 · nε 1.97
Pleochroism
Non-pleochroic
Notes

Anomalous biaxial character exhibited in some crystals with a very small 2V.

Michel-Lévy diagramhighlighted lineδ = 0.1600
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1600 nm3rd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1600 nm
Order3rd order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
#58
Cell parameters
a = 3.7725 Å · b = 3.7742 Å · c = 21.726 Å
Cell angles
α = 90 ° · β = 90 ° · γ = 90 °
Ratio a:b:c
1 : 1.000 : 5.759
Unit cell volume
309.4 ų
Z
2
Morphology

Rectangular plates flattened (001) forming spherical and radial-fibrous structures. Compact earthy masses.

Type-locality form

Pulverulent earthy masses and drusy crystals; massive earthy. The crystals are sparkling rectangular plates up to 0.5 mm. The plates are extremely thin and are commonly grouped into subparallel aggregates or rosettes.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
83BiBismuthBismuth2208.980417.960
68.51%
8OOxygenOxygen815.999127.992
20.98%
20CaCalciumCalcium140.07840.078
6.57%
6CCarbonCarbon212.01124.022
3.94%
Total610.052100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Beyeriet

In other languages

German
Beyerit
Spanish
Beyerita
Italian
Beyerite

Classification

Strunz
10th ed.

5.BE.35

  • 5CarbonatesClass
  • 5.BCarbonates with additional anions, without H2ODivision
  • 5.BEWith Pb, BiGroup
  • 5.BE.35BeyeriteSpecies
Dana
8th ed.

16a.02.03.01

  • 16aAnhydrous Carbonates Containing Hydroxyl or HalogenClass
  • 16a.02(AB)3(XO3)2ZqType
  • 16a.02.03— unnamed intermediate level —Group
  • 16a.02.03.01BeyeriteSpecies
CIM

11.10.2

  • 11CarbonatesClass
  • 11.10Carbonates of BiGroup
  • 11.10.2BeyeriteSpecies

Group, growth & confusion

Often grow together
1 mineral

Literature, links & citation

Citations
  1. Lagercrantz and Sillén (1948) Arkiv för Kemi, Mineralogi och Geologi, Stockholm: 25: 1-21.
  2. 1921Larsen, E.S. (1921) The Microscopic Determination of the Nonopaque Minerals, First edition, USGS Bulletin 679: 49 (on Bismutosphaerite believed to be beyerite).
  3. 1943Frondel, Clifford (1943) The mineralogy of the oxides and carbonates of bismuth. American Mineralogist, 28 (9-10) 521-535
  4. 1947Heinrich, E. Wm. (1947) Beyerite from Colorado. American Mineralogist, 32 (11-12) 660-669
  5. 1951Palache, Charles; Berman, Harry; Frondel, Clifford (1951) The System of Mineralogy (7th ed.) Vol. 2 - Halides, Nitrates, Borates, Carbonates, Sulfates, Phosphates, Arsenates, Tungstates, Molybdates, Etc. John Wiley and Sons.
