Blixite

Pb8O5(OH)2Cl4
IMA status
  • Approved
  • Grandfathered
IMA symbol
Blx
Also known as
  • Blixiet

Where it forms, where it's found

Geological setting

In hausmannite-rich dolomite and manganophyllite skarn in a metamorphosed Fe-Mn orebody

Reaction product of slags immersed in sea water

Type locality
Långban Mine
  1. Långban Ore District
  2. Filipstad
  3. Värmland County
  4. Sweden

59.8554°, 14.2648°

11recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789103/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Pale yellow · yellow-orange to greyish yellow
Streak
Pale yellow
Cleavage
Distinct/Good

in one direction

Density
7.35 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 80°
Refractive index
2.05 – 2.2
Surface relief
Very high
Principal indices
nα 2.05 · nγ 2.20
Dispersion
r < v, strong
Michel-Lévy diagramhighlighted lineδ = 0.1500
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1500 nm3rd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1500 nm
Order3rd order
XPL colour

Crystallography

Crystal system
Orthorhombic
Cell parameters
a = 5.832 Å · b = 5.694 Å · c = 25.47 Å
Ratio a:b:c
1 : 0.976 : 4.367
Z
8
Morphology

Massive, in films

Twinning

On (100), synthetic.

Type-locality form

Massive

Comment

Orthorhombic or monoclinic. Point Group: 2/m (synthetic). ; Space Group: C2/c (synthetic).

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead8207.2001657.600
86.63%
17ClChlorineChlorine435.450141.800
7.41%
8OOxygenOxygen715.999111.993
5.85%
1HHydrogenHydrogen21.0082.016
0.11%
Total1913.409100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ca
  • Cu
  • Fe
  • Zn

Synonyms

  • Blixiet

In other languages

German
Blixit
Italian
Blixite
Chinese
氯氧铅矿

Classification

Strunz
10th ed.

3.DC.50

  • 3HalidesClass
  • 3.DOxyhalides, hydroxyhalides and related double halidesDivision
  • 3.DCWith Pb (As,Sb,Bi), without CuGroup
  • 3.DC.50BlixiteSpecies
Dana
8th ed.

10.02.04.01

  • 10Oxyhalides and HydroxyhalidesClass
  • 10.02A(O,OH)XqType
  • 10.02.04— unnamed intermediate level —Group
  • 10.02.04.01BlixiteSpecies
CIM

8.8.11

  • 8Halides - Fluorides, Chlorides, Bromides and Iodides; also Fluoborates and FluosilicatesClass
  • 8.8Halides of PbGroup
  • 8.8.11BlixiteSpecies

Literature, links & citation

Citations
  1. 1960Fleischer, M. (1960) New mineral names. American Mineralogist, 45 (7-8). 908-910
  2. 1960Gabrielson, Olof, Parwel, Alexander, Wickman, Frans E. (1960) Blixite, a new lead-oxyhalide mineral from Långban. Arkiv för Mineralogi och Geologi, 2 (5). 411-415
  3. 1969Welin, E. (1969) Notes on the mineralogy of Sweden 6. X-ray powder data for minerals from Långban and the related mineral deposits of Central Sweden. Arkiv för Mineralogi och Geologi, 4 (6, nr 30). 499-541
  4. 1994Scott, K. M. (1994) Lead oxychlorides at Elura, western NSW, Australia. Mineralogical Magazine, 58 (391) 336-338 doi:10.1180/minmag.1994.058.391.17 DOI: 10.1180/minmag.1994.058.391.17
  5. 1997Anthony, J. W., et al. (1997) Handbook of Mineralogy, Vol. 3: 67.
