Bolivarite

Al2(PO4)(OH)3 · 4H2O
IMA status
  • Approved
  • Grandfathered
  • Questionable
IMA symbol
Bva
Discovered
1921

Where it forms, where it's found

Geological setting

Crevices in granite.

Type locality
Pontevedra
  1. Galicia
  2. Spain
5recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Colour
Pale greenish-yellow
Fracture
Splintery · Conchoidal
Density
1.97 g/cm³

Optical

UV response
Strongly fluorescent in green
Notes

Biaxial to uniaxial+

Isotropy testPPL ↔ XPL diagnostic
PPL intrinsic colour; no change on stage rotation
XPL extinct at every orientation

Crystallography

Crystal system
Amorphous
Morphology

Cryptocrystalline crusts.

Comment

Amorphous to 1050 degrees

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1115.999175.989
64.70%
13AlAluminiumAluminium226.98253.964
19.84%
15PPhosphorusPhosphorus130.97430.974
11.39%
1HHydrogenHydrogen111.00811.088
4.07%
Total272.015100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • U

In other languages

German
Bolivarit
Italian
Bolivarite
Chinese
隐磷铝石

Classification

Strunz
10th ed.

8.DF.10

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.DPhosphates, etc. with additional anions, with H2ODivision
  • 8.DFWith only medium-sized cations, (OH,etc.):RO4 > 3:1Group
  • 8.DF.10BolivariteSpecies
Dana
8th ed.

42.06.08.01

  • 42Hydrated Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 42.06A2(XO4)Zq·xH2OType
  • 42.06.08— unnamed intermediate level —Group
  • 42.06.08.01BolivariteSpecies
CIM

19.7.7

  • 19PhosphatesClass
  • 19.7Phosphates of Al aloneGroup
  • 19.7.7BolivariteSpecies

Literature, links & citation

Citations
  1. 1921Navarro, L.F., Barea, P.C. (1921) La ‹bolivarita›, nueva especie mineral. Boletín de la Real Sociedad Española de Historia Natural: 21: 326-328.
  2. 1951Palache, Charles; Berman, Harry; Frondel, Clifford (1951) The System of Mineralogy (7th ed.) Vol. 2 - Halides, Nitrates, Borates, Carbonates, Sulfates, Phosphates, Arsenates, Tungstates, Molybdates, Etc. John Wiley and Sons.
  3. 1971Van Wambeke, L. (1971) The uranium-bearing mineral bolivarite: new data and a second occurrence. Mineralogical Magazine, 38 (296) 418-423 doi:10.1180/minmag.1971.038.296.03 DOI: 10.1180/minmag.1971.038.296.03
  4. 1976Duncan McConnell, (1976) Crystallinity among some hydrous aluminium phosphates. Mineralogical Magazine, 40 (314) 609-610 doi:10.1180/minmag.1976.040.314.08 DOI: 10.1180/minmag.1976.040.314.08
  5. 1995García-Guinea, J., Chagoyen, A.M., Nickel, E.H. (1995) A re-investigation of bolivarite and evansite. The Canadian Mineralogist: 33: 59-65.
