Bradleyite

Na3Mg(PO4)(CO3)
IMA status
  • Approved
  • Grandfathered
IMA symbol
Bd
Discovered
1941
Also known as
  • Bradleyiet

Where it forms, where it's found

Geological setting

Oil shale deposit. Secondary mineral after shortite.

Product of postgenetic crystallization of fluid inclusions in minerals from carbonatites and kimberlites. In melt inclusions in diamonds. Chloride-carbonatite nodules in kimberlite. Syngenetic primary inclusion in early-crystallized minerals in carbonatites from the alkaline-carbonatite complexes. [[1]]

Type locality
John Hay Jr. Well No. 1
  1. Sweetwater County
  2. Wyoming
  3. USA

41.5681°, -109.8006°

24recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103 – 4/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Light grey
Fracture
Conchoidal
Density
2.734 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 49° · 2V calc = 50°
Refractive index
1.487 – 1.56
Surface relief
Moderate
Principal indices
nα 1.487 · nβ 1.546 · nγ 1.560
Dispersion
none
Michel-Lévy diagramhighlighted lineδ = 0.0730
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]730 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation730 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21/m
Cell parameters
a = 8.684(9) Å · b = 6.804(6) Å · c = 5.074(5) Å
Cell angles
β = 90.34(5) °
Ratio a:b:c
1 : 0.784 : 0.584
Z
2
Morphology

Extremely fine-grained masses.

Type-locality form

extremely fine-grained masses.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen715.999111.993
45.11%
11NaSodiumSodium322.99068.970
27.78%
15PPhosphorusPhosphorus130.97430.974
12.48%
12MgMagnesiumMagnesium124.30524.305
9.79%
6CCarbonCarbon112.01112.011
4.84%
Total248.253100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Bradleyiet

In other languages

German
Bradleyit
Italian
Bradleyite
Chinese
磷碳镁钠石

Classification

Strunz
10th ed.

5.BF.10

  • 5CarbonatesClass
  • 5.BCarbonates with additional anions, without H2ODivision
  • 5.BFWith (Cl), SO4, PO4, TeO3Group
  • 5.BF.10BradleyiteSpecies
Dana
8th ed.

43.02.01.01

  • 43Compound Phosphates, Etc.Class
  • 43.02Anhydrous Normal Compound Phosphates, etc·Type
  • 43.02.01Bradleyite GroupGroup
  • 43.02.01.01BradleyiteSpecies
CIM

22.4.1

  • 22Phosphates, Arsenates or Vanadates with other AnionsClass
  • 22.4Phosphates, arsenates or vanadates with carbonateGroup
  • 22.4.1BradleyiteSpecies

Group, growth & confusion

Often grow together
1 mineral

Literature, links & citation

Citations
  1. 1941Fahey, Joseph J., Tunell, George (1941) Bradleyite, a new mineral, sodium phosphate-magnesium carbonate. American Mineralogist, 26 (11) 646-650
  2. 1946Brasseur (1946) Bull. soc. roy. sc. Liége: 15: 527.
  3. 1951Palache, Charles; Berman, Harry; Frondel, Clifford (1951) The System of Mineralogy (7th ed.) Vol. 2 - Halides, Nitrates, Borates, Carbonates, Sulfates, Phosphates, Arsenates, Tungstates, Molybdates, Etc. John Wiley and Sons.
  4. 1984Tjy, C.T.L., Nadezhina, T.N., Pobedimskaya, E.A., Khomyakov, A.P. (1984) The crystal-chemical characteristics of bradleyite, sidorenkite and bonshtedtite. Mineralogiceskij Zhurnal: 6: 79-84. (in Russian)
  5. 2007(2007) Bradleyite. Handbook of Mineralogy. Mineralogical Society of America
