Branchite

C20H34
IMA status
  • Approved
IMA symbol
Bran
Also known as
  • Bombiccite
  • Branchiet
  • Hofmannite
  • +7 more

Where it forms, where it's found

Geological setting

in lignite seams and fractures in fossil coalified and silicified tree trunks

Type locality
Lignite mines
  1. Hart
  2. Enzenreith
  3. Neunkirchen District
  4. Lower Austria
  5. Austria

47.6706°, 15.9489°

11recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789101/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
white · grey · yellowish grey · colourless
Tenacity
waxy
Cleavage
Very Good
Density
1.036 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 57°
Refractive index
1.546 – 1.587
Surface relief
Moderate
Principal indices
nα 1.546 · nβ 1.555 · nγ 1.587
Dispersion
r > v
UV response
none
Michel-Lévy diagramhighlighted lineδ = 0.0410
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]410 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation410 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#1
Cell parameters
a = 11.407 Å · b = 20.952 Å · c = 7.406 Å
Cell angles
α = 93.941 ° · β = 100.75 ° · γ = 80.499 °
Ratio a:b:c
1 : 1.837 : 0.649
Z
4
Morphology

complex flattened to needlelike crystals to 8 mm (26 forms noted), lamellar to coarse crystalline masses or coatings

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
6CCarbonCarbon2012.011240.220
87.51%
1HHydrogenHydrogen341.00834.272
12.49%
Total274.492100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Bombiccite
  • Branchiet
  • Hofmannite
  • Iosene
  • Josen
  • Josene
  • Krantzite
  • psatyrite
  • Rhetenite
  • α-Phyllocladane

In other languages

German
Branchit · Hartit
Italian
bombiccite · branchite · Hartite · hofmannite · iosene · josene · krantzite · rhetenite

Classification

Strunz
10th ed.

10.BA.10

  • 10Organic CompoundsClass
  • 10.BHydrocarbonsDivision
  • 10.BAHydrocarbonsGroup
  • 10.BA.10BranchiteSpecies

Literature, links & citation

Citations
  1. 1841Haidinger, W. (1841) Ueber den Hartit, eine neue Species aus der Ordnung der Erdharze. Annalen der Physik und Chemie: 130: 261-265.
  2. 1856Kenngott, G.A. (1856): Ueber den Piauzit von Tüffer und den Hartit von Rosenthal in Steiermark. Jahrbuch der k.k. Geologischen Reichsanstalt 7, 91-95. [https://opac.geologie.ac.at/wwwopacx/wwwopac.ashx?command=getcontent&server=images&value=JB0071_091_A.pdf]
  3. 1870Rumpf, J. (1870) Ueber neuere Mineralfunde im tertiären Kohlenbecken von Voitsberg - Lankowitz. Mitteilungen des Naturwissenschaftlichen Vereines für Steiermark: 7: 204-214. [detailed crystallographic study]
  4. 1921Boeris, G. (1921) Sulla composizione della hofmannite. Atti della Accademia delle Scienze dell'Istituto di Bologna, Classe di Scienze Fisiche, Rendiconti, 25.
  5. 1933Hintze, C. (1933) Handbuch der Mineralogie, Vol. 1, de Gruyter (Berlin). 1358-1360.
