Britvinite

Pb14Mg9(Si10O28)(BO3)4(CO3)2(OH)12F2
IMA status
  • Approved
IMA symbol
Bv
IMA approved
2006
Also known as
  • Britviniet
  • IMA2006-031
  • Molybdophyllite-18 Å

Where it forms, where it's found

Type locality
Långban Mine
  1. Långban Ore District
  2. Filipstad
  3. Värmland County
  4. Sweden

59.8554°, 14.2648°

2recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789103/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
pale yellow to colorless
Streak
white
Tenacity
flexible
Cleavage
Distinct/Good

parallel to (001).

Flexible in thin lamella, thick one is brittle

Density
5.51 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 20°
Refractive index
1.896 – 1.903
Surface relief
Very high
Principal indices
nα 1.896 · nβ 1.903 · nγ 1.903
Michel-Lévy diagramhighlighted lineδ = 0.0070
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]70 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation70 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#1
Cell parameters
a = 9.3409(8) Å · b = 9.3579(7) Å · c = 18.8333(14) Å
Cell angles
α = 80.365(6) ° · β = 75.816(6) ° · γ = 59.870(5) °
Ratio a:b:c
1 : 1.002 : 2.016
Unit cell volume
1378.7 ų
Z
2
Type-locality form

plates

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead14207.2002900.800
65.25%
8OOxygenOxygen5815.999927.942
20.87%
14SiSiliconSilicon1028.085280.850
6.32%
12MgMagnesiumMagnesium924.305218.745
4.92%
5BBoronBoron410.81043.240
0.97%
9FFluorineFluorine218.99837.996
0.86%
6CCarbonCarbon212.01124.022
0.54%
1HHydrogenHydrogen121.00812.096
0.27%
Total4445.691100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Britviniet
  • IMA2006-031
  • Molybdophyllite-18 Å

In other languages

German
Britvinit · IMA 2006-031
Italian
britvinite

Classification

Strunz
10th ed.

9.EG.70

  • 9SilicatesClass
  • 9.EPhyllosilicatesDivision
  • 9.EGDouble nets with 6-membered and larger ringsGroup
  • 9.EG.70BritviniteSpecies

Literature, links & citation

Citations
  1. 1988Charalampides, G. and Lindqvist, B. (1988): Ganomalite, margarosanite and molybdophyllite from Långban, south-central Sweden, and synthetic equivalents. Meddelanden från Stockholms Universitets Geologiska Institution, 273, IV/1-IV/24.
  2. 1994Charalampides, G. (1994): Mineralogical and crystal-chemical data of the lead silicate species ganomalite, margarosanite, and molybdophyllite from Långban, south-central Sweden and their synthetic equivalents. Oryktos Ploutos, 91, 33-46.
  3. 2007Chukanov N. V.; Yakubovich, O. V.; Pekov, I. V.; Belakovsky, D.I.; Massa, W. (2007) Бритвинит Pb15Mg9(Si10O28)(BO3)4(CO3)2(OH)12O2-новый минерал из Лонгбана, Швеция [Britvinite, Pb15Mg9(Si10O28)(BO3)4(CO3)2(OH)12O2-a new mineral from Langban, Sweden]. Записки Российского Минералогического Общества [Zapiski RMO (Proceedings of the Russian Mineralogical Society)], 136 (6). 18-25
  4. 2008Yakubovich, O.V., Massa, W., Chukanov, N.V. (2008) Crystal structure of britvinite [Pb7(OH)3F(BO3)2(CO3)][Mg4.5(OH)3(Si5O14)]: A new layered silicate with an original type of silicon-oxygen networks: Kristallografiya: 53(2): 233–242.
  5. 2008Yakubovich, O.V., Massa, W., Chukanov, N.V. (2008) Crystal structure of britvinite [Pb7(OH)3F(BO3)2(CO3)][Mg4.5(OH)3(Si5O14)]: A new layered silicate with an original type of silicon-oxygen networks. Crystallography Reports: 53: 206-215. (English translation)
