Cafetite

CaTi2O5 · H2O
IMA status
  • Approved
IMA symbol
Cft
Discovered
1959
Also known as
  • Cafetiet

Where it forms, where it's found

Geological setting

Late hydrothermal mineral in miarolitic cavities, in pegmatite that cuts pyroxenite.

Type locality
Afrikanda complex
  1. Murmansk Oblast
  2. Russia

67.4313°, 32.7556°

7recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104 – 5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
yellow · colourless
Streak
white
Tenacity
brittle
Cleavage
Distinct/Good

Two cleavage planes

Density
3.28 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 36.5 – 39° · 2V calc = 48°
Refractive index
1.95 – 2.11
Surface relief
Very high
Principal indices
nα 1.95 · nβ 2.08 · nγ 2.11
Dispersion
strong
Extinction
Z ∧ c=2 ◦ –4 Z ^ c = 2-4°
Michel-Lévy diagramhighlighted lineδ = 0.1600
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1600 nm3rd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1600 nm
Order3rd order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#14
Cell parameters
a = 4.9436(15) Å · b = 12.109(4) Å · c = 15.911(5) Å
Cell angles
β = 98.937(5) °
Ratio a:b:c
1 : 2.449 : 3.219
Unit cell volume
940.9 ų
Z
8
Morphology

Columnar to acicular crystals, elongated || z and with striated prism faces. Forms (100), (520), (210). Fibrous masses, radiating aggregates.

Type-locality form

Tangled fibrous aggregates and radial-fibrous aggregates of acicular crystals.

Comment

Space group setting is P21/n !

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen615.99995.994
41.06%
22TiTitaniumTitanium247.86795.734
40.94%
20CaCalciumCalcium140.07840.078
17.14%
1HHydrogenHydrogen21.0082.016
0.86%
Total233.822100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Cafetiet

In other languages

French
Cafetite
German
Cafetit
Spanish
Cafetita
Italian
Cafetite

Classification

Strunz
10th ed.

4.FL.75

  • 4OxidesClass
  • 4.FHydroxides (without V or U)Division
  • 4.FLHydroxides with H2O +- (OH); sheets of edge-sharing octahedraGroup
  • 4.FL.75CafetiteSpecies
Dana
8th ed.

08.07.03.01

  • 08Multiple Oxides Containing Niobium, Tantalum or TitaniumClass
  • 08.07MiscellaneousType
  • 08.07.03— unnamed intermediate level —Group
  • 08.07.03.01CafetiteSpecies
CIM

7.9.24

  • 7Oxides and HydroxidesClass
  • 7.9Oxides of TiGroup
  • 7.9.24CafetiteSpecies

Literature, links & citation

Citations
  1. 1959Kukharenko, A.A., Kondrat´Eva, V.V., Kovyazina, V.M. (1959) Cafetite, a new hydrous titanate of calcium and iron. Zapiski Vserossijskogo Mineralogicheskogo Obshchestva: 88: 444-453.
  2. 1960Fleischer, M. (1960) New mineral names. American Mineralogist, 45 (3-4). 476-480
  3. 2003Krivovichev, Sergey V., Yakovenchuk, Victor N., Burns, Peter C., Pakhomovsky, Yakov A., Menshikov, Yury P. (2003) Cafetite, Ca[Ti2O5](H2O): Crystal structure and revision of chemical formula. American Mineralogist, 88 (2) 424-429 doi:10.2138/am-2003-2-318 DOI: 10.2138/am-2003-2-318
  4. 2013Bortolozzi, G., Boscardini, M., Rocchetti, I., Bersani, D. (2013) Cafetite e kassite della cava di Pilcante in Val d'Adige (Ala, Trento). Micro: 11(1): 39-48.
  5. 2021(2021) Cafetite. Handbook of Mineralogy. Mineralogical Society of America
