Calciborite

CaB2O4
IMA status
  • Approved
  • Grandfathered
IMA symbol
Cbo
Discovered
1955
Also known as
  • Calciboriet

Where it forms, where it's found

Geological setting

a contact metasomatized limestone near a quartz diorite intrusion associated with a copper deposit in skarn.

Type locality
Novofrolovskoye B-Cu deposit
  1. Tur'insk
  2. Turya river
  3. Serovsky District
  4. Sverdlovsk Oblast
  5. Russia

59.7833°, 60.5000°

2recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Colorless to white
Fracture
Irregular/Uneven · Conchoidal
Density
2.878 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 54° · 2V calc = 52°
Refractive index
1.595 – 1.67
Surface relief
Moderate
Principal indices
nα 1.595 · nβ 1.654 · nγ 1.670
Dispersion
r > v or r < v
Michel-Lévy diagramhighlighted lineδ = 0.0750
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]750 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation750 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
Pccn
Cell parameters
a = 8.38 Å · b = 13.82 Å · c = 5.00 Å
Ratio a:b:c
1 : 1.649 : 0.597
Z
8
Type-locality form

Prismatic crystals, to 1.5 cm

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen415.99963.996
50.91%
20CaCalciumCalcium140.07840.078
31.89%
5BBoronBoron210.81021.620
17.20%
Total125.694100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Calciboriet

In other languages

French
Calciborite
German
Calciborit
Italian
Calciborite
Russian
Кальциборит

Classification

Strunz
10th ed.

6.BC.10

  • 6BoratesClass
  • 6.BDiboratesDivision
  • 6.BCIno-diborates with triangles and/or tetrahedraGroup
  • 6.BC.10CalciboriteSpecies
Dana
8th ed.

24.05.02.01

  • 24Anhydrous BoratesClass
  • 24.05MiscellaneousType
  • 24.05.02— unnamed intermediate level —Group
  • 24.05.02.01CalciboriteSpecies
CIM

9.3.1

  • 9BoratesClass
  • 9.3Borates of Ca and SrGroup
  • 9.3.1CalciboriteSpecies

Literature, links & citation

Citations
  1. 1955Petrova, E.S. (1955) Calciborite, a new mineral (in Russian). Geology of Mining and Chemical Raw Materials: ?: 218–223.
  2. 1956Fleischer, M. (1956) New mineral names. American Mineralogist, 41 (9-10). 814-816
  3. 1956Petrova, E.S. (1956) Sbornik "Geol. orno-khim, Syr'e". Trudy Gosudarst Nauchno-Issled. Inst. Gorno-khim. Syr'ya: 2: 218-223.
  4. 1956Petrova, E.S. (1956) Calciborite - Ca5B8O17. Zapiski Vsesoyuznogo Mineralogicheskogo Obshchestva: 85: 76-76.
  5. 1963Malinko, S.V., Kuznetsova, N.N., Pensionerova, V.M., Rybakova, L.I. (1963) New data on calcioborite. Zapiski Vsesoyuznogo Mineralogicheskogo Obshchestva: 92: 684-690.
