Calcjarlite

Na2(Ca,◻)14(Mg,◻)2Al12F64(OH)4
IMA status
  • Approved
  • Grandfathered
IMA symbol
Cjar
Discovered
1973
Also known as
  • Calcjarliet

Where it forms, where it's found

Type locality
Fluorite vein
  1. Parvaya Noiba River
  2. Enisei Range (Yenisei Ridge
  3. Enisei Ridge)
  4. Krasnoyarsk Krai
  5. Russia

Physical

Hardness
123456789104/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Colour
White
Cleavage
None Observed
Fracture
Irregular/Uneven
Density
3.51 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 72° · 2V calc = 82°
Refractive index
1.425 – 1.432
Surface relief
Low
Principal indices
nα 1.425 · nβ 1.428 · nγ 1.432
Dispersion
not discernible
Michel-Lévy diagramhighlighted lineδ = 0.0070
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]70 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation70 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Cell parameters
a = 16.19 Å · b = 9.86 Å · c = 7.15 Å
Cell angles
β = 99.2 °
Ratio a:b:c
1 : 0.609 : 0.442
Comment

Monoclinic symmetry assumed by analogy to jarlite.

Synonyms

  • Calcjarliet

In other languages

German
Calcjarlit
Italian
Calcjarlite

Classification

Strunz
10th ed.

3.CC.20

  • 3HalidesClass
  • 3.CComplex halidesDivision
  • 3.CCSoro-aluminofluoridesGroup
  • 3.CC.20CalcjarliteSpecies
Dana
8th ed.

11.06.10.02

  • 11Halide ComplexesClass
  • 11.06Aluminofluorides - Isolated OctahedraType
  • 11.06.10Jarlite GroupGroup
  • 11.06.10.02CalcjarliteSpecies
CIM

8.4.13

  • 8Halides - Fluorides, Chlorides, Bromides and Iodides; also Fluoborates and FluosilicatesClass
  • 8.4Halides of the alkaline earths and MgGroup
  • 8.4.13CalcjarliteSpecies

Literature, links & citation

Citations
  1. 1970Nozhkin, A.D., Moleva, V.A., Chubkova, T.P. (1970) First find of jarlite in the U.S.S.R.. Zapiski Vsesoyuznogo Mineralogicheskogo Obshchestva: 99(4): 458-462.
  2. 1973Povarennykh, A.S. (1973) On the new mineral species calcjarlite. Konstitutsiya i Svoistva Mineralov: 7: 131-135.
  3. 1974Fleischer, Michael (1974) New mineral names. American Mineralogist, 59 (7-8). 873-875
  4. 1983Hawthorne, F. C. (1983) The crystal structure of jarlite. The Canadian Mineralogist, 21 (3) 553-560
  5. 2005(2005) Calcjarlite. Handbook of Mineralogy. Mineralogical Society of America
