Cesbronite

Cu3Te6+O4(OH)4
IMA status
  • Approved
IMA symbol
Ces
Discovered
1974
Also known as
  • Cesbroniet
  • Cesbronite-x
  • IMA1974-006

Where it forms, where it's found

Geological setting

Oxidized tellurium-copper-lead veins. Very late stage.

Type locality
Bambollita Mine
  1. Moctezuma
  2. Moctezuma Municipality
  3. Sonora
  4. Mexico

29.6925°, -109.7081°

4recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Emerald green · 'green beetle'

Dark green in transmitted light.

Streak
Pale green
Tenacity
brittle
Cleavage
Distinct/Good

Poor on (010); good on (021).

Density
4.45 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 72° · 2V calc = 74°
Refractive index
1.88 – 2.029
Surface relief
Very high
Principal indices
nα 1.880 · nβ 1.928 · nγ 2.029
Pleochroism
Strong

X = pale bluish green; Y = dark yellow-green; Z = dark emerald-green.

Dispersion
r > v, moderate.
Extinction
X = a; Y = c; Z = b.
Notes

Absorption: X ≃ Y >> Z.

Michel-Lévy diagramhighlighted lineδ = 0.1490
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1490 nm3rd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1490 nm
Order3rd order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
Cmcm
Cell parameters
a = 2.93172(16) Å · b = 11.8414(6) Å · c = 8.6047(4) Å
Ratio a:b:c
1 : 4.039 : 2.935
Morphology

Chisel-shaped dipyramidal crystals showing dominant and striated (103), with (180), (001), and (010). As hollow crusts of radiating crystals and fanlike aggregates.

Type-locality form

Green crystals sometimes forming hollow spherical crusts.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
29CuCopperCopper363.546190.638
42.34%
8OOxygenOxygen815.999127.992
28.43%
52TeTelluriumTellurium1127.600127.600
28.34%
1HHydrogenHydrogen41.0084.032
0.89%
Total450.262100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Cesbroniet
  • Cesbronite-x
  • IMA1974-006

In other languages

French
Cesbronite
German
Cesbronit · IMA 1974-006
Italian
Cesbronite · Cesbronite-x
Chinese
羟碲铜矿

Classification

Strunz
10th ed.

4.JN.15

  • 4OxidesClass
  • 4.JArsenites, antimonites, bismuthites, sulfites, selenites, tellurites; iodatesDivision
  • 4.JNTellurites with additional anions, with H2OGroup
  • 4.JN.15CesbroniteSpecies
Dana
8th ed.

34.07.02.01

  • 34Selenites, Tellurites and SulfitesClass
  • 34.07Hydrated Selenites, Tellurites and Sulfites containing Hydroxyl or HalogenType
  • 34.07.02— unnamed intermediate level —Group
  • 34.07.02.01CesbroniteSpecies
CIM

28.3.5

  • 28Selenites, Selenates, Tellurites, and TelluratesClass
  • 28.3TelluritesGroup
  • 28.3.5CesbroniteSpecies

Literature, links & citation

Citations
  1. Canadian Mineralogist: 34: 49-54, 55-59.
  2. 1974Williams, Sidney A. (1974) Cesbronite, a new copper tellurite from Moctezuma, Sonora. Mineralogical Magazine, 39 (307) 744-746 doi:10.1180/minmag.1974.039.307.02 DOI: 10.1180/minmag.1974.039.307.02
  3. 1979Fleischer, Michael, Chao, George Y., Mandarino, J. A. (1979) New mineral names. American Mineralogist, 64 (5-6) 652-659
  4. 2005(2005) Cesbronite. Handbook of Mineralogy. Mineralogical Society of America
  5. 2017Hålenius, U., Hatert, F., Pasero, M., Mills, S. J. (2017) New minerals and nomenclature modifications approved in 2017, CNMNC Newsletter No 39. Mineralogical Magazine, 81 (5) 1279-1286 doi:10.1180/minmag.2017.081.072DOI: 10.1180/minmag.2017.081.072
