Changbaiite

PbNb2O6
IMA status
  • Approved
  • Grandfathered
IMA symbol
Chg
Discovered
1978
Also known as
  • Changbaiiet

Where it forms, where it's found

Type locality
Mt Gang
  1. Ji'an Co.
  2. Tonghua
  3. Jilin
  4. China
4recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789105.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Colorless · cream-white · pale brown · yellowish brown · pale yellowish green.
Streak
White
Tenacity
brittle
Cleavage
Perfect

(0001), perfect; one rhombohedral, distinct.

Fracture
Hackly · Conchoidal
Density
6.48 g/cm³

Optical

Optical type
Uniaxial (+)
Refractive index
2.476 – 2.485
Surface relief
Very high
Principal indices
nω 2.476 · nε 2.485
Michel-Lévy diagramhighlighted lineδ = 0.0090
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]90 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation90 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
#86
Cell parameters
a = 10.51 Å · c = 11.55 Å
Z
9
Type-locality form

Tabular crystals or spherules, to 5 mm.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead1207.200207.200
42.37%
41NbNiobiumNiobium292.906185.812
38.00%
8OOxygenOxygen615.99995.994
19.63%
Total489.006100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Changbaiiet

In other languages

German
Changbaiit
Italian
Changbaiite

Classification

Strunz
10th ed.

4.DF.10

  • 4OxidesClass
  • 4.DMetal: Oxygen = 1:2 and similarDivision
  • 4.DFWith large (+- medium-sized) cations; dimers and trimers of edgesharing octahedraGroup
  • 4.DF.10ChangbaiiteSpecies
Dana
8th ed.

08.03.11.01

  • 08Multiple Oxides Containing Niobium, Tantalum or TitaniumClass
  • 08.03AB2O6Type
  • 08.03.11— unnamed intermediate level —Group
  • 08.03.11.01ChangbaiiteSpecies
CIM

18.1.24

  • 18Niobates and TantalatesClass
  • 18.1Niobates and tantalates containing neither rare earths nor UGroup
  • 18.1.24ChangbaiiteSpecies

Literature, links & citation

Citations
  1. Comptes rendu de l’Académie des sciences de Paris 263C, 217-219.
  2. 1978Detachment No. 8, Comprehensive Geological Brigade of Tonghua Region and the Laboratory of Petrology and Mineralogy Laboratory and Jilin Institute of Geological Science (1978): Changbaiite (PbNb2O6), a new mineral of lead and niobium from eastern Kirin, China. Acta Geologica Sinica 52(1), 53-62 (in Chinese with English abstract). - American Mineralogist (1979), 64, 242 (abstract).
  3. 1978Detachment No. 8, Comprehensive Geological Brigade of Tonghua Region and the Laboratory of Petrology and Mineralogy Laboratory and Jilin Institute of Geological Science (1978): Changbaiite (PbNb2O6), a new mineral of lead and niobium from eastern Kirin, China. Acta Geologica Sinica 52(1), 53-62 (in Chinese with English abstract).
  4. 2005(2005) Changbaiite. Handbook of Mineralogy. Mineralogical Society of America
