Chekhovichite

Bi3+2Te4+4O11
IMA status
  • Approved
IMA symbol
Ckh
Discovered
1987
Also known as
  • Chekhovichiet
  • IMA1986-039

Where it forms, where it's found

Geological setting

In fractures in quartz and chalcedony in oxidized ores.

Rare oxidation product of tellurides.

Type locality
Sotk gold mine
  1. Sotk
  2. Gegharkunik Province
  3. Armenia

40.2330°, 45.9680°

6recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Grayish yellow · pale gray · or grayish green
Streak
White
Cleavage
Perfect

One perfect parallel to elongation. Less perfect 87 degrees from first cleavage.

Density
6.88 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 65° · 2V calc = 64°
Refractive index
2.45 – 2.65
Surface relief
Very high
Principal indices
nα 2.45 · nβ 2.5 · nγ 2.65
Dispersion
r < v strong
Optical colour
Pale gray to gray
Anisotropism
Marked
Bireflectance
Observable
Internal reflections
White
Tropism
Anisotropic
Reflectance R%
(18.9,21.4) 400, (18.8,21.4) 420, (18.7,21.3) 440, (18.6,21.3) 460, (18.3,21.2) 480, (18.1,21.2) 500, (18.1,21.1) 520, (17.9,21.0) 540, (17.7,20.8) 560, (17.6,20.7) 580, (17.4,20.6) 600, (17.3,21.5) 620, (17.3,20.4) 640, (17.2,20.3) 660, (17.2,20.2) 680, (17.1,20.2) 700
Reflected-light panel
17.9 %anisotropic · dual curve
Specimen sRGB 155, 108, 60
White reference100 % reflector under same lamp
R₁ R₂
Mode
Bireflectance
Observable
Anisotropism
Marked
Reflected colour
Pale gray to gray
Internal reflections
White

Crystallography

Crystal system
Monoclinic
Cell parameters
a = 18.8963(8) Å · b = 7.9563(8) Å · c = 6.9909(3) Å
Cell angles
β = 95.176(3) °
Ratio a:b:c
1 : 0.421 : 0.370
Z
4
Morphology

Subhedral platy grains

Twinning

Polysynthetic, parallel elongation.

Type-locality form

Crusts on quartz, as small pockets in limonite, and as pseudomorphs after tellurobismuthite. Aggregates are up to 5 mm across; individual grains are up to 0.1 mm in size.

Comment

On synthetic material

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
52TeTelluriumTellurium4127.600510.400
46.22%
83BiBismuthBismuth2208.980417.960
37.85%
8OOxygenOxygen1115.999175.989
15.93%
Total1104.349100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Chekhovichiet
  • IMA1986-039

In other languages

German
Chekhovichit · IMA 1986-039
Italian
Chekhovichite
Chinese
切铋碲矿

Classification

Strunz
10th ed.

4.JK.35

  • 4OxidesClass
  • 4.JArsenites, antimonites, bismuthites, sulfites, selenites, tellurites; iodatesDivision
  • 4.JKTellurites without additional anions, without H2OGroup
  • 4.JK.35ChekhovichiteSpecies
Dana
8th ed.

34.06.04.01

  • 34Selenites, Tellurites and SulfitesClass
  • 34.06Anhydrous Selenites, Tellurites and Sulfites containing Hydroxyl or HalogenType
  • 34.06.04— unnamed intermediate level —Group
  • 34.06.04.01ChekhovichiteSpecies
CIM

28.3.17

  • 28Selenites, Selenates, Tellurites, and TelluratesClass
  • 28.3TelluritesGroup
  • 28.3.17ChekhovichiteSpecies

Literature, links & citation

Citations
  1. 1972Frit, Bernard; Jaymes, Michel (1972) Le système Bi2O3-TeO2 à 450°C. Revue de Chimie Minerale: 9: 837-844.
  2. 1987Spiridonov, E.M., Petrova, I.V., Demina, L.A., Dolgikh, V.I., Antonyan, G.M. (1987) The new mineral chekhovichite (Bi2Te4O11). Vestnik Moskovskogo Universiteta, Geologiya (Moscow University Geology Bulletin): 42(6): 71-75.
  3. 1989Jambor, John L., Burke, Ernst A. J. (1989) New Mineral Names. American Mineralogist, 74 (11-12) 1399-1404
  4. 1992Rossell, H.J., Leblanc, M., Férey, G., Bevan, D.J.M., Simpson, D.J., Taylor, M.R. (1992) On the crystal structure of Bi2Te4O11. Australian Journal of Chemistry: 45: 1415-1425.
  5. 1996Szaller, Zs., Pöppl, L., Lovas, Gy., Dódonyc, I. (1996) Study of the Formation of Bi2Te4O11. Journal of Solid State Chemistry: 121(2): 251-261.
