Chiappinoite-(Y)

Y2Mn(Si3O7)4
IMA status
  • Approved
IMA symbol
Cap-Y
IMA approved
2014
Also known as
  • Chiappinoiet-(Y)
  • IMA2014-040

Where it forms, where it's found

Geological setting

In peralkaline syenitic ejecta from the Água de Pau volcano.

Type locality
Água de Pau Volcano
  1. São Miguel
  2. Azores
  3. Portugal

Physical

Hardness
123456789106/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Colourless
Tenacity
brittle
Cleavage
Perfect

on (001).

Fracture
Irregular/Uneven
Density
3.09 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 24° · 2V calc = 25°
Refractive index
1.59 – 1.5982
Surface relief
Moderate
Principal indices
nα 1.590 · nβ 1.5978 · nγ 1.5982
Pleochroism
Non-pleochroic
Dispersion
Exhibits no dispersion
Michel-Lévy diagramhighlighted lineδ = 0.0082
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]82 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation82 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
#55
Cell parameters
a = 7.5549(3) Å · b = 15.2342(2) Å · c = 19.6418(14) Å
Ratio a:b:c
1 : 2.016 : 2.600
Unit cell volume
2260.6 ų
Z
4
Morphology

Thin to thick prisms, up to 1 mm long, with blunt chisel-like terminations. Forms observed: (100), (010), (001), (110) and (011).

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2815.999447.972
44.02%
14SiSiliconSilicon1228.085337.020
33.11%
39YYttriumYttrium288.906177.812
17.47%
25MnManganeseManganese154.93854.938
5.40%
Total1017.742100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ce
  • Ca
  • Fe(II)
  • Dy
  • Na
  • Nd
  • Er
  • Gd
  • La
  • Yb

Synonyms

  • Chiappinoiet-(Y)
  • IMA2014-040

In other languages

German
Chiappinoit-(Y) · IMA 2014-040
Italian
chiappinoite-(Y)

Classification

Strunz
10th ed.

9.DP.45

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DPTransitional ino-phyllosilicate structuresGroup
  • 9.DP.45Chiappinoite-(Y)Species

Literature, links & citation

Citations
  1. 2014Williams, P. A., Hatert, F., Pasero, M., Mills, S. J. (2014) IMA Commission on New Minerals, Nomenclature and Classification (CNMNC), CNMNC Newsletter No. 22. Mineralogical Magazine, 78 (5) 1241-1248 doi:10.1180/minmag.2014.078.5.10DOI: 10.1180/minmag.2014.078.5.10
  2. 2015Kampf, Anthony R., Housley, Robert M. (2015) Chiappinoite-(Y), Y2Mn(Si3O7)4, a new layer silicate found in peralkaline syenitic ejecta from the Água de Pau volcano, Azores. European Journal of Mineralogy, 27 (1). 91-97 doi:10.1127/ejm/2014/0026-2416 DOI: 10.1127/ejm/2014/0026-2416
  3. 2015Belakovskiy, Dmitriy I., Cámara, Fernando, Gagne, Olivier C., Uvarova, Yulia (2015) New Mineral Names. American Mineralogist, 100 (8) 2005-2013 doi:10.2138/am-2015-nmn1008-98DOI: 10.2138/am-2015-nmn1008-98
  4. 2016(2016) Chiappinoite-(Y). Handbook of Mineralogy. Mineralogical Society of America
