Chlorbartonite

K6Fe24S26Cl
IMA status
  • Approved
IMA symbol
Cbtn
Discovered
1998
IMA approved
2000
Also known as
  • Chlorbartoniet
  • IMA2000-048

Where it forms, where it's found

Geological setting

A low-temperature hydrothermal mineral. Found in hydrothermal veins in feldspathic urtite.

Type locality
Koashva Open Pit
  1. Koashva Mt
  2. Murmansk Oblast
  3. Russia

67.6167°, 34.0000°

9recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Brown-black
Streak
Black
Tenacity
brittle
Cleavage
None Observed
Fracture
Conchoidal
Density
3.70 g/cm³

Optical

Optical colour
yellowish brown
Internal reflections
none observed
Tropism
Isotropic
Reflectance R%
(9.8) 420, (10.8) 470, (11.5) 500, (13.5) 546, (14.0) 560, (15.1) 589, (16.4) 620, (17.2) 650, (18.4) 680, (19.5) 720
Reflected-light panel
14.6 %isotropic · single curve
Specimen sRGB 152, 94, 39
White reference100 % reflector under same lamp
Reflected colour
yellowish brown
Internal reflections
none observed

Crystallography

Crystal system
Tetragonal
Space group
#176
Cell parameters
a = 10.3810(8) Å · b = 20.614(2) Å
Unit cell volume
2221.5 ų
Z
2
Parting
None observed
Type-locality form

Equant grains (up to 2 cm in diameter) within sodalite.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
26FeIronIron2455.8451340.280
54.84%
16SSulfurSulfur2632.060833.560
34.11%
19KPotassiumPotassium639.098234.588
9.60%
17ClChlorineChlorine135.45035.450
1.45%
Total2443.878100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Chlorbartoniet
  • IMA2000-048

In other languages

German
Chlorbartonit · IMA 2000-048
Italian
Chlorbartonite · Clorbartonite

Classification

Strunz
10th ed.

2.FC.10

  • 2Sulfides and SulfosaltsClass
  • 2.FSulfides of arsenic, alkalies; sulfides with halide, oxide, hydroxide, H2ODivision
  • 2.FCWith Cl, Br, I (halide-sulfides)Group
  • 2.FC.10ChlorbartoniteSpecies

Literature, links & citation

Citations
  1. 2003Jambor, John L., Roberts, Andrew C. (2003) New mineral names. American Mineralogist, 88. 1836-1840
  2. 2003Yakovenchuk, V. N., Pakhomovsky, Y. A., Men'shikov, Y. P., Ivanyuk, G. Yu., Krivovichev, S. V., Burns, P. C. (2003) Chlorbartonite, K6Fe24S26(Cl,S), a new mineral species from a hydrothermal vein in the Khibina massif, Kola Peninsula, Russia: Description and crystal structure. The Canadian Mineralogist, 41 (2) 503-511 doi:10.2113/gscanmin.41.2.503 DOI: 10.2113/gscanmin.41.2.503
  3. 2006Azarova, Y.V., Krinov, D.I., Sokolova, M.N. (2006) A structural and genetic relationship of djerfisherite and bartonite, and the problem of isomorphous substitutions in the system djerfisherite - "Cu-djerfisherite" - bartonite. New Data on Minerals: 41: 98-107.
  4. 2007(2007) New Minerals From Former Soviet Union Countries 1998-2006. Mineralogical Almanac Vol. 11
  5. 2021(2021) Chlorbartonite. Handbook of Mineralogy. Mineralogical Society of America
