Christelite

Zn3Cu2(SO4)2(OH)6 · 4H2O
IMA status
  • Approved
IMA symbol
Cis
Also known as
  • Christeliet
  • IMA1995-030

Where it forms, where it's found

Type locality
San Francisco Mine
  1. Caracoles
  2. Caracoles mining district
  3. Sierra Gorda
  4. Antofagasta Province
  5. Antofagasta
  6. Chile

-22.8786°, -69.3369°

5recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102 – 3/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Transparent
Colour
Greenish-blue
Streak
Bright greenish blue
Cleavage
Perfect

On (001)

Density
3.14 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 59.4° · 2V calc = 59.00°
Refractive index
1.5977 – 1.6354
Surface relief
Moderate
Principal indices
nα 1.5977 · nβ 1.6259 · nγ 1.6354
Pleochroism
Visible

α = pale blue, and β and γ = blue

Dispersion
r < v weak
UV response
Not fluorescent
Michel-Lévy diagramhighlighted lineδ = 0.0377
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]377 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation377 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 5.4143(8) Å · b = 6.336(1) Å · c = 10.470(3) Å
Cell angles
α = 94.32(3) ° · β = 90.06(2) ° · γ = 90.27(2) °
Ratio a:b:c
1 : 1.170 : 1.934
Z
2
Morphology

As thin bladed crystals, flattened on (001).

Type-locality form

Thin, greenish blue, transparent crystals, up to 4 x 13 mm, flattened on (010)

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1815.999287.982
41.77%
30ZnZincZinc365.380196.140
28.45%
29CuCopperCopper263.546127.092
18.43%
16SSulfurSulfur232.06064.120
9.30%
1HHydrogenHydrogen141.00814.112
2.05%
Total689.446100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Christeliet
  • IMA1995-030

In other languages

German
Christelit · IMA 1995-030
Italian
Christelite
Chinese
硫铜锌矿

Classification

Strunz
10th ed.

7.DD.25

  • 7SulfatesClass
  • 7.DSulfates (selenates, etc.) with additional anions, with H2ODivision
  • 7.DDWith only medium-sized cations; sheets of edge-sharing octahedraGroup
  • 7.DD.25ChristeliteSpecies

Literature, links & citation

Citations
  1. 1996Adiwidjaja, G., Friese, K., Klaska, K.-H., Schlüter, J. (1996) The crystal structure of christelite Zn3Cu2(SO4)2(OH)6·4H2O. Zeitschrift für Kristallographie - Crystalline Materials, 211 (8) 518-521 doi:10.1524/zkri.1996.211.8.518 DOI: 10.1524/zkri.1996.211.8.518
  2. 1996Schlüter, J., Klaska, K.-H., Adiwidjaja, G., Gebhard, G. (1996) Christelite, Zn3Cu2(SO4)2(OH)6•4H2O, a new mineral from the San Francisco Mine, Antofagasta, Chile. Neues Jahrbuch für Mineralogie - Monatshefte, 1996. 188-192
  3. 1997Mandarino, Joseph A. (1997) Abstracts of New Minerals Descriptions. The Mineralogical Record, 28 (5) 401-405
  4. 1997Jambor, J.L., Roberts, A.C. (1997) New mineral names. American Mineralogist, 82, 207-210.
  5. 2005(2005) Christelite. Handbook of Mineralogy. Mineralogical Society of America
