Chromschieffelinite

Pb10Te6+6O20(OH)14(CrO4)(H2O)5
IMA status
  • Approved
IMA symbol
Csfl
IMA approved
2011
Also known as
  • Chromschieffeliniet
  • IMA2011-003

Where it forms, where it's found

Geological setting

oxidation zone of hydrothermal ore deposit containing tellurides and galena.

Type locality
Bird Nest drift
  1. Otto Mountain
  2. Baker
  3. Soda Mountains
  4. Silver Lake Mining District
  5. San Bernardino County
  6. California
  7. USA

35.2767°, -116.1001°

1recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789102/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Colour
pale yellow
Streak
pale yellow
Tenacity
brittle
Cleavage
Perfect

(010)

Density
5.892 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 68° · 2V calc = 69.6°
Refractive index
1.93 – 1.975
Surface relief
Very high
Principal indices
nα 1.930 · nβ 1.960 · nγ 1.975
Pleochroism
Non-pleochroic
Dispersion
r < v, strong
Michel-Lévy diagramhighlighted lineδ = 0.0450
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]450 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation450 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
C2 2 21
Cell parameters
a = 9.6646(3) Å · b = 19.4962(8) Å · c = 10.5101(7) Å
Ratio a:b:c
1 : 2.017 : 1.087
Z
2
Type-locality form

blocky to tabular on (010) with striations parallel to [001] and are up to 0.2 mm in maximum dimension.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead10207.2002072.000
57.53%
52TeTelluriumTellurium6127.600765.600
21.26%
8OOxygenOxygen4315.999687.957
19.10%
24CrChromiumChromium151.99651.996
1.44%
1HHydrogenHydrogen241.00824.192
0.67%
Total3601.745100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Chromschieffeliniet
  • IMA2011-003

In other languages

German
Chromschieffelinit · IMA 2011-003
Italian
chromschieffelinite

Classification

Strunz
10th ed.

7.DF

  • 7SulfatesClass
  • 7.DSulfates (selenates, etc.) with additional anions, with H2ODivision
  • 7.DFWith large and medium-sized cationsGroup
  • 7.DFChromschieffeliniteSpecies

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 2010Marty, J., Kampf, A. R., Housley, R. M., Mills, S. J., Weiß, S. (2010) Seltene neue Tellurmineralien aus Kalifornien, Utah, Arizona und New Mexiko (USA) Lapis, 35 (12) 42-51
  2. 2011Williams, P. A., Hatert, F., Pasero, M., Mills, S. J. (2011) New minerals and nomenclature modifications approved in 2011. CNMNC Newsletter No 9. Mineralogical Magazine, 75 (4) 2535-2540 doi:10.1180/minmag.2011.075.4.2535 DOI: 10.1180/minmag.2011.075.4.2535
  3. 2012Kampf, A. R., Mills, S. J., Housley, R. M., Rumsey, M. S., Spratt, J. (2012) Lead-tellurium oxysalts from Otto Mountain near Baker, California: VII. Chromschieffelinite, Pb10Te6O20(OH)14(CrO4)(H2O)5, the chromate analog of schieffelinite. American Mineralogist, 97 (1) 212-219 doi:10.2138/am.2011.3909 DOI: 10.2138/am.2011.3909
  4. 2014(2014) Chromschieffelinite. Handbook of Mineralogy. Mineralogical Society of America
