Cobaltoblödite

Na2Co(SO4)2 · 4H2O
IMA status
  • Approved
IMA symbol
Cblö
Also known as
  • Cobaltoblödiet
  • IMA2012-059

Where it forms, where it's found

Geological setting

Post mining. Formed in moist adits in a sandstone-hosted uranium deposit.

Type locality
Blue Lizard Mine
  1. Red Canyon Mining District
  2. San Juan County
  3. Utah
  4. USA

37.5572°, -110.2968°

1recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Reddish-pink in aggregates.
Streak
White
Tenacity
brittle
Cleavage
None Observed
Fracture
Irregular/Uneven
Density
2.29 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 70° · 2V calc = 64°
Refractive index
1.498 – 1.505
Surface relief
Moderate
Principal indices
nα 1.498 · nβ 1.503 · nγ 1.505
Pleochroism
Non-pleochroic
Dispersion
r > v, weak.
UV response
Not fluorescent.
Michel-Lévy diagramhighlighted lineδ = 0.0070
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]70 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation70 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21/a
Cell parameters
a = 11.147(1) Å · b = 8.268(1) Å · c = 5.5396(7) Å
Cell angles
β = 100.517(11) °
Ratio a:b:c
1 : 0.742 : 0.497
Z
2
Parting
none
Type-locality form

Aggregates of anhedral grains up to 200 μm forming thin crusts covering areas up to 2×2 cm on the surface of other sulfates.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1215.999191.988
52.02%
16SSulfurSulfur232.06064.120
17.37%
27CoCobaltCobalt158.93358.933
15.97%
11NaSodiumSodium222.99045.980
12.46%
1HHydrogenHydrogen81.0088.064
2.18%
Total369.085100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Cobaltoblödiet
  • IMA2012-059

In other languages

German
Cobaltoblödit · IMA 2012-059
Italian
cobaltoblödite

Classification

Strunz
10th ed.

7.CC

  • 7SulfatesClass
  • 7.CSulfates (selenates, etc.) without additional anions, with H2ODivision
  • 7.CCWith medium-sized and large cationsGroup
  • 7.CCCobaltoblöditeSpecies

Group, growth & confusion

In the same group
4 members
Often grow together
1 mineral

Literature, links & citation

Citations
  1. 2013Williams, P. A., Hatert, F., Pasero, M., Mills, S. J. (2013) IMA Commission on New Minerals, Nomenclature and Classification. CNMNC Newsletter No. 15. Mineralogical Magazine, 77 (1) 1-12 doi:10.1180/minmag.2013.077.1.01DOI: 10.1180/minmag.2013.077.1.01
  2. 2013Kasatkin, A. V., Nestola, F., Plášil, J., Marty, J., Belakovskiy, D. I., Agakhanov, A. A., Mills, S. J., Pedron, D., Lanza, A., Favaro, M., Bianchin, S., Lykova, I. S., Goliáš, V., Birch, W. D. (2013) Manganoblödite, Na2Mn(SO4)2·4H2O, and cobaltoblödite, Na2Co(SO4)2·4H2O: two new members of the blödite group from the Blue Lizard mine, San Juan County, Utah, USA. Mineralogical Magazine, 77 (3) 367-383 doi:10.1180/minmag.2013.077.3.10 DOI: 10.1180/minmag.2013.077.3.10
  3. 2016(2016) Cobaltoblödite. Handbook of Mineralogy. Mineralogical Society of America
  4. 2018Marinova, Delyana, Wildner, Manfred, Bancheva, Tsvetelina, Stoyanova, Radostina, Georgiev, Mitko, Stoilova, Donka G. (2018) Synthesis, structure and properties of blödite-type solid solutions, Na2Co1−xCux(SO4)2·4H2O (0 < x ≤ 0.18), and crystal structure of synthetic kröhnkite, Na2Cu(SO4)2·2H2O. Physics and Chemistry of Minerals, 45 (8) 801-817 doi:10.1007/s00269-018-0963-0DOI: 10.1007/s00269-018-0963-0
