Colinowensite

BaCuSi2O6
IMA status
  • Approved
IMA symbol
Cwn
IMA approved
2012
Also known as
  • Colinowensiet
  • Han Purple
  • IMA2012-060

Where it forms, where it's found

Type locality
Wessels Mine
  1. Joe Morolong Local Municipality
  2. John Taolo Gaetsewe District Municipality
  3. Northern Cape
  4. South Africa

-27.1135°, 22.8544°

1recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Purple to dark blue (when thicker)
Streak
Purple
Tenacity
brittle
Fracture
Irregular/Uneven
Density
4.20 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.73 – 1.745
Surface relief
High
Principal indices
nω 1.740 – 1.745 · nε 1.735 – 1.730
Pleochroism
Strong

Purple along the c axis to blue in a perpendicular direction.

UV response
None observed.
Michel-Lévy diagramhighlighted lineδ = 0.0100
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]100 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation100 nm
Order1st order
XPL colour

Crystallography

Crystal system
Tetragonal
Space group
#177
Cell parameters
a = 9.967(1) Å · c = 22.290(2) Å
Unit cell volume
2221.4 ų
Z
16
Morphology

(100) and (110). (001) is always present as cleavage planes.

Type-locality form

Subhedral crystals to 100 × 100 × 50 μm, but most do not exceed 50 μm in any direction.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
56BaBariumBarium1137.327137.327
38.90%
8OOxygenOxygen615.99995.994
27.19%
29CuCopperCopper163.54663.546
18.00%
14SiSiliconSilicon228.08556.170
15.91%
Total353.037100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Colinowensiet
  • Han Purple
  • IMA2012-060

In other languages

German
Colinowensit · IMA 2012-060
Italian
colinowensite

Classification

Strunz
10th ed.

9.C0

  • 9SilicatesClass
  • 9.CCyclosilicatesDivision
  • 9.C0— unnamed intermediate level —Group
  • 9.C0ColinowensiteSpecies

Literature, links & citation

Citations
  1. 1989Finger, L. W., Hazen, R. M., Hemley, R. J. (1989) BaCuSi2O6: A new cyclosilicate with four-membered tetrahedral rings. American Mineralogist, 74 (7-8) 952-955
  2. 2004Sparta, K.M., Roth, G. (2004) Reinvestigation of the structure of BaCuSi2O6 - evidence for a phase transition at high temperature. Acta Crystallographica: B60: 491-495.
  3. 2013Williams, P. A., Hatert, F., Pasero, M., Mills, S. J. (2013) IMA Commission on New Minerals, Nomenclature and Classification. CNMNC Newsletter No. 15. Mineralogical Magazine, 77 (1) 1-12 doi:10.1180/minmag.2013.077.1.01DOI: 10.1180/minmag.2013.077.1.01
  4. 2014Chen, Y., Zhang, Y., Feng, S. (2014) Hydrothermal synthesis and properties of pigments Chinese purple BaCuSi2O6 and dark blue BaCu2Si2O7. Dyes and Pigments: 105: 167-173.
  5. 2015Rieck, B., Pristacz, H., Giester, G. (2015) Colinowensite, BaCuSi2O6, a new mineral from the Kalahari Manganese Field, South Africa and new data on wesselsite, SrCuSi4O10. Mineralogical Magazine, 79 (7) 1769-1778 doi:10.1180/minmag.2015.079.7.04 DOI: 10.1180/minmag.2015.079.7.04
