Curetonite

Ba(Al,Ti)(PO4)(OH,O)F
IMA status
  • Approved
IMA symbol
Cut
Discovered
1978
IMA approved
1978
Also known as
  • Curetoniet
  • IMA1978-065

Where it forms, where it's found

Geological setting

Barite deposit. In veins in cherts and shales that have been replaced by barite.

Type locality
Redhouse Barite Mine
  1. Potosi Mining District
  2. Osgood Mountains
  3. Humboldt County
  4. Nevada
  5. USA

41.0986°, -117.3025°

1recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Bright green yellowish
Streak
White
Tenacity
brittle
Cleavage
Distinct/Good

Good on (011)

Density
4.42 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 60° · 2V calc = 58.4°
Refractive index
1.676 – 1.693
Surface relief
High
Principal indices
nα 1.676 · nβ 1.68 · nγ 1.693
Pleochroism
Visible

In patchy yellows

Dispersion
weak r < v
Michel-Lévy diagramhighlighted lineδ = 0.0170
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]170 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation170 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Cell parameters
a = 6.977(2) Å · b = 12.564(4) Å · c = 5.223(1) Å
Cell angles
β = 101.15(2) °
Ratio a:b:c
1 : 1.801 : 0.749
Z
4
Morphology

Wedgelike. May be elongated along [001], showing (100), (010), (001), (011), and (201).

Twinning

Polysynthetic on (100)

Parting
On (010)
Comment

Space Group: P21/n.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
56BaBariumBarium1137.327137.327
38.24%
8OOxygenOxygen615.99995.994
26.73%
22TiTitaniumTitanium147.86747.867
13.33%
15PPhosphorusPhosphorus130.97430.974
8.62%
13AlAluminiumAluminium126.98226.982
7.51%
9FFluorineFluorine118.99818.998
5.29%
1HHydrogenHydrogen11.0081.008
0.28%
Total359.150100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Curetoniet
  • IMA1978-065

In other languages

German
Curetonit · IMA 1978-065
Italian
Curetonite
Chinese
磷钛铝钡石

Classification

Strunz
10th ed.

8.BK.15

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.BPhosphates, etc., with additional anions, without H2ODivision
  • 8.BKWith medium-sized and large cations, (OH, etc.):RO4 = 2:1, 2.5:1Group
  • 8.BK.15CuretoniteSpecies
Dana
8th ed.

41.05.15.01

  • 41Anhydrous Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 41.05(AB)2(XO4)ZqType
  • 41.05.15— unnamed intermediate level —Group
  • 41.05.15.01CuretoniteSpecies
CIM

19.5.12

  • 19PhosphatesClass
  • 19.5Phosphates of Sr and BaGroup
  • 19.5.12CuretoniteSpecies

Literature, links & citation

Citations
  1. 1979Williams, Sidney A. (1979) Curetonite, a new phosphate from Nevada, in July - August 1979. The Mineralogical Record, 10 (4) 219-221
  2. 1980Fleischer, M.; Mandarino, J.A.; Pabst, A. (1980) New mineral names. American Mineralogist, 65 (1-2). 205-210
  3. 1994Cooper, Mark, Hawthorne, Frank C. (1994) The crystal structure of curetonite, a complex heteropolyhedral sheet mineral. American Mineralogist, 79 (5-6) 545-549
  4. 2005(2005) Curetonite. Handbook of Mineralogy. Mineralogical Society of America
