Cymrite

Ba(Si,Al)4(O,OH)8 · H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Cym
Discovered
1949
Also known as
  • Cymriet

Where it forms, where it's found

Geological setting

veins in manganese silicates

Type locality
Benallt Mine
  1. Rhiw
  2. Aberdaron
  3. Gwynedd
  4. Wales
  5. UK

52.8207°, -4.6390°

42recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102 – 3/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Colourless · green · brown

Green and brown colours are caused by inclusions of alteration products.

Streak
White
Tenacity
brittle
Cleavage
Perfect

Perfect on (001), imperfect on (110)

Fracture
Irregular/Uneven
Density
3.413 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 5°
Refractive index
1.611 – 1.621
Surface relief
Moderate
Principal indices
nα 1.611 · nβ 1.619 · nγ 1.621
Dispersion
relatively strong
UV response
Greenish white
Notes

pseudouniaxial.

Michel-Lévy diagramhighlighted lineδ = 0.0100
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]100 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation100 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21
Cell parameters
a = 5.329(5) Å · b = 36.6 Å · c = 7.681(22) Å
Cell angles
β = 90 °
Ratio a:b:c
1 : 6.868 : 1.441
Z
8
Type-locality form

As thin pseudohexagonal platelets and prisms, to 7 mm; also fibrous

Comment

pseudohexagonal

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1715.999271.983
42.52%
56BaBariumBarium1137.327137.327
21.47%
14SiSiliconSilicon428.085112.340
17.56%
13AlAluminiumAluminium426.982107.928
16.87%
1HHydrogenHydrogen101.00810.080
1.58%
Total639.658100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Fe
  • Mn
  • K

Synonyms

  • Cymriet

In other languages

German
Cymrit
Italian
Cymrite

Classification

Strunz
10th ed.

9.EG.05

  • 9SilicatesClass
  • 9.EPhyllosilicatesDivision
  • 9.EGDouble nets with 6-membered and larger ringsGroup
  • 9.EG.05CymriteSpecies
Dana
8th ed.

78.01.03.01

  • 78Unclassified SilicatesClass
  • 78.01MiscellaneousType
  • 78.01.03— unnamed intermediate level —Group
  • 78.01.03.01CymriteSpecies
CIM

16.12.6

  • 16Silicates Containing Aluminum and other MetalsClass
  • 16.12Aluminosilicates of Sr, Ba and ZnGroup
  • 16.12.6CymriteSpecies

Literature, links & citation

Citations
  1. 1949Smith, W. Campbell, Bannister, F. A., Hey, Max H. (1949) Cymrite, a new barium mineral from the Benallt manganese mine, Rhiw, Carnarvonshire. Mineralogical Magazine and Journal of the Mineralogical Society, 28 (206) 676-681 doi:10.1180/minmag.1949.28.206.02 DOI: 10.1180/minmag.1949.28.206.02
  2. 1950Fleischer, M. (1950) New mineral names. American Mineralogist, 35 (1-2) 135-136
  3. 1964Seki, Yôtarô, Kennedy, George C. (1964) Phase relations between cymrite, BaAlSi3O8(OH), and celsian, BaAl2Si2O8. American Mineralogist, 49 (9-10) 1407-1426
  4. 1964Runnells, D.D. (1964). Cymrite in a copper deposit, Brooks Range, Alaska. The American Mineralogist, 49, 158-165.
  5. 1966Kashaev, A.A. (1966) The crystal structure of cymrite. Doklady Akademii Nauk SSSR, 169, 201-203.
