Damaraite

Pb3O2(OH)Cl
IMA status
  • Approved
IMA symbol
Dm
Discovered
1990
Also known as
  • Damaraiet
  • IMA1989-013

Where it forms, where it's found

Geological setting

Polymetallic hydrothermal and metasomatic replacement and fracture-filling of dolostones.

Type locality
Asis West sector
  1. Kombat Mine
  2. Kombat
  3. Otavi Constituency
  4. Otjozondjupa Region
  5. Namibia

-19.7050°, 17.6903°

1recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789103/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Colourless
Streak
White
Tenacity
brittle
Cleavage
Distinct/Good

On (010)

Fracture
Irregular/Uneven · Sub-Conchoidal
Density
7.84 g/cm³

Optical

Optical type
Biaxial
Pleochroism
Weak

Barely detectable bluish grey to grey.

Dispersion
r > v strong
Optical colour
Gray
Anisotropism
Weak
Bireflectance
Weak
Internal reflections
White
Tropism
Anisotropic
Reflectance R%
(19.1,20.8) 400, (18.6,23.1) 420, (17.9,21.1) 440, (17.4,19.4) 460, (16.9,18.5) 480, (16.6,17.9) 500, (16.2,17.4) 520, (16.0,17.0) 540, (15.8,16.7) 560, (15.6,16.5) 580, (15.5,16.3) 600, (15.4,16.2) 620, (15.2,16.0) 640, (15.2,15.9) 660, (15.1,15.8) 680, (15.0,15.6) 700
Reflected-light panel
16.3 %anisotropic · dual curve
Specimen sRGB 146, 103, 59
White reference100 % reflector under same lamp
R₁ R₂
Mode
Bireflectance
Weak
Anisotropism
Weak
Reflected colour
Gray
Internal reflections
White

Crystallography

Crystal system
Orthorhombic
Space group
#32
Cell parameters
a = 5.813 Å · b = 6.921 Å · c = 15.192 Å
Ratio a:b:c
1 : 1.191 : 2.613
Unit cell volume
611.2 ų
Z
4
Parting
Possible parting
Type-locality form

Subhedral grains, < 200x150 um, in interstices in calcite.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead3207.200621.600
88.04%
8OOxygenOxygen315.99947.997
6.80%
17ClChlorineChlorine135.45035.450
5.02%
1HHydrogenHydrogen11.0081.008
0.14%
Total706.055100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Damaraiet
  • IMA1989-013

In other languages

German
Damarait · IMA 1989-013
Italian
Damaraite

Classification

Strunz
10th ed.

3.DC.75

  • 3HalidesClass
  • 3.DOxyhalides, hydroxyhalides and related double halidesDivision
  • 3.DCWith Pb (As,Sb,Bi), without CuGroup
  • 3.DC.75DamaraiteSpecies
Dana
8th ed.

10.05.10.01

  • 10Oxyhalides and HydroxyhalidesClass
  • 10.05Am(O,OH)pXqType
  • 10.05.10— unnamed intermediate level —Group
  • 10.05.10.01DamaraiteSpecies
CIM

8.8.6

  • 8Halides - Fluorides, Chlorides, Bromides and Iodides; also Fluoborates and FluosilicatesClass
  • 8.8Halides of PbGroup
  • 8.8.6DamaraiteSpecies

Literature, links & citation

Citations
  1. 1990Criddle, A. J., Keller, P., Stanley, C. J., Innes, J. (1990) Damaraite, a new lead oxychloride mineral from the Kombat mine, Namibia (South West Africa) Mineralogical Magazine, 54 (377) 593-598 doi:10.1180/minmag.1990.054.377.10 DOI: 10.1180/minmag.1990.054.377.10
  2. 2001Keller, Paul, Lissner, Falk, Schleid, Thomas (2001) Damaraite, Pb3O2(OH)Cl: crystal structure and new chemical formula. Neues Jahrbuch für Mineralogie - Monatshefte, 2001. 326-336
  3. 2001Krivovichev, Sergey V., Burns, Peter C. (2001) Crystal chemistry of lead oxide chlorides. I. Crystal structures of synthetic mendipite, Pb3O2Cl2, and synthetic damaraite, Pb3O2(OH)Cl. European Journal of Mineralogy, 13 (4) 801-809 doi:10.1127/0935-1221/2001/0013-0801DOI: 10.1127/0935-1221/2001/0013-0801
  4. 2005(2005) Damaraite. Handbook of Mineralogy. Mineralogical Society of America
