Dargaite

BaCa12(SiO4)4(SO4)2O3
IMA status
  • Approved
IMA symbol
Drg
IMA approved
2015
Also known as
  • Dargaiet
  • IMA2015-068

Where it forms, where it's found

Geological setting

pyrometamorphic rock

Type locality
Nahal Darga
  1. Bethlehem Governorate
  2. West Bank
  3. Palestine

31.5883°, 35.3728°

1recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104.5 – 5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Colorless
Streak
white
Tenacity
brittle
Cleavage
Poor/Indistinct

(001)

Density
3.235 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.639 – 1.643
Surface relief
Moderate
Principal indices
nω 1.643 · nε 1.639
Pleochroism
Non-pleochroic
UV response
none
Michel-Lévy diagramhighlighted lineδ = 0.0040
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]40 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation40 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
#86
Cell parameters
a = 7.1874(4) Å · c = 41.292(3) Å
Unit cell volume
1847.32 ų
Z
3
Parting
pronounced

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
20CaCalciumCalcium1240.078480.936
39.21%
8OOxygenOxygen2715.999431.973
35.21%
56BaBariumBarium1137.327137.327
11.19%
14SiSiliconSilicon428.085112.340
9.16%
16SSulfurSulfur232.06064.120
5.23%
Total1226.696100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Dargaiet
  • IMA2015-068

In other languages

German
Dargait · IMA 2015-068

Classification

Strunz
10th ed.

9.AH.35

  • 9SilicatesClass
  • 9.ANesosilicatesDivision
  • 9.AHNesosilicates with CO3, SO4, PO4, etc.Group
  • 9.AH.35DargaiteSpecies

Group, growth & confusion

In the same group
3 members
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 2015Hålenius, U., Hatert, F., Pasero, M., Mills, S. J. (2015) New minerals and nomenclature modifications approved in 2015, CNMNC Newsletter no 28. Mineralogical Magazine, 79 (7) 1859-1864 doi:10.1180/minmag.2015.079.7.18DOI: 10.1180/minmag.2015.079.7.18
  2. 2019Galuskina, Irina O., Gfeller, Frank, Galuskin, Evgeny V., Armbruster, Thomas, Vapnik, Yevgeny, Dulski, Mateusz, Gardocki, Mariusz, Jeżak, Lidia, Murashko, Mikhail (2019) New minerals with modular structure derived from hatrurite from the pyrometamorphic rocks. Part IV: Dargaite, BaCa12(SiO4)4(SO4)2O3, from Nahal Darga, Palestinian Autonomy. Mineralogical Magazine, 83 (1) 81-88 doi:10.1180/minmag.2017.081.095 DOI: 10.1180/minmag.2017.081.095
  3. 2020(2020) Dargaite. Handbook of Mineralogy. Mineralogical Society of America
