Davreuxite

Mn2+Al6Si4O17(OH)2
IMA status
  • Approved
  • Grandfathered
IMA symbol
Drx
Discovered
1878
Also known as
  • Davreuxiet

Where it forms, where it's found

Type locality
Ottré
  1. Bihain
  2. Vielsalm
  3. Luxembourg
  4. Wallonia
  5. Belgium

50.2489°, 5.8366°

9recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102 – 3/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Creamy-white · pale rose pink
Tenacity
brittle
Cleavage
Distinct/Good

Good on (100).

Cross fractures on {010}.

Density
3.30 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 48° · 2V calc = 52°
Refractive index
1.66 – 1.69
Surface relief
High
Principal indices
nα 1.66 · nβ 1.684 · nγ 1.69
Dispersion
weak
Michel-Lévy diagramhighlighted lineδ = 0.0300
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]300 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation300 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21/m
Cell parameters
a = 9.55 Å · b = 5.77 Å · c = 12.88 Å
Cell angles
β = 116.82 °
Ratio a:b:c
1 : 0.604 : 1.349
Z
2
Type-locality form

fibrous masses in quartz veins, in close association with pyrophyllite and kaolinite.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1915.999303.981
47.86%
13AlAluminiumAluminium626.982161.892
25.49%
14SiSiliconSilicon428.085112.340
17.68%
25MnManganeseManganese154.93854.938
8.65%
1HHydrogenHydrogen21.0082.016
0.32%
Total635.167100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ti
  • Fe
  • Cr
  • Cu
  • Zn
  • Mg
  • P

Synonyms

  • Davreuxiet

In other languages

German
Davreuxit
Italian
Davreuxite
Chinese
达硅铝锰石

Classification

Strunz
10th ed.

9.BF.15

  • 9SilicatesClass
  • 9.BSorosilicatesDivision
  • 9.BFSorosilicates with mixed SiO4 and Si2O7 groups; cations in tetrahedral [4] and greater coordinationGroup
  • 9.BF.15DavreuxiteSpecies
Dana
8th ed.

58.01.02.01

  • 58Sorosilicates Insular, Mixed, Single, and Larger Tetrahedral GroupsClass
  • 58.01Insular, Mixed, Single, and Larger Tetrahedral Groups with cations in [4] and higher coordination; single and double groups (n=1, 2)Type
  • 58.01.02— unnamed intermediate level —Group
  • 58.01.02.01DavreuxiteSpecies
CIM

16.16.3

  • 16Silicates Containing Aluminum and other MetalsClass
  • 16.16Aluminosilicates of MnGroup
  • 16.16.3DavreuxiteSpecies

Literature, links & citation

Citations
  1. Van Der Meersche, Eddy, De Paepe, Paul, Stoops, Georges (n.d.) Minerals with Belgian Roots - from hopeite (1824) to tazieffite (2009) Academia Press, Ghent.
  2. 1878de Koninck, L.L. (1878) Sur la davreuxite, espèce nouvelle recueillie dans les filons de quartz du terrain ardennais. Bulletin de l'Académie Royale de Belgique, Série II, 46(8), 240-245.
  3. 1886Lacroix, A. (1886) Propriétés optiques de quelques minéraux (wavellite, variscite, planérite et davreuxite). Bulletin de la Société française de Minéralogie, 9, 4.
  4. 1970Strunz, H. (1970) Mineralogische Tabellen. 5. Auflage. Akademische Verlagsgesellschaft Geest & Portig, Leipzig.
  5. 1976Fransolet, A.M., Bourguignon, P. (1976) Mineralogical data on davreuxite. Comptes Rendus des Séances de l'Académie des Sciences, Série D: Sciences Naturelles 283(4), 295-297 (in French).
