Demesmaekerite

Pb2Cu5(UO2)2(Se4+O3)6(OH)6 · 2H2O
IMA status
  • Approved
IMA symbol
Dmm
Discovered
1965
Also known as
  • Demesmaekeriet
  • IMA1965-019

Where it forms, where it's found

Type locality
Musonoi Mine
  1. Kolwezi
  2. Mutshatsha
  3. Lualaba
  4. DR Congo

-10.7135°, 25.4454°

3recorded occurrences
Source · OpenStreetMap

Radioactivity

Physical

Hardness
123456789103 – 4/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent · Opaque
Colour
Bottle-green when fresh · turning somewhat brownish on dehydration
Cleavage
None Observed
Density
5.28 g/cm³

Optical

Optical type
Biaxial (+)
Refractive index
1.835 – 1.91
Surface relief
Very high
Principal indices
nα 1.835 · nγ 1.910
Pleochroism
Visible

X' = yellow-green; Y' = brown.

Dispersion
strong
Michel-Lévy diagramhighlighted lineδ = 0.0750
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]750 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation750 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 11.94 Å · b = 10.02 Å · c = 5.62 Å
Cell angles
α = 90 ° · β = 100 ° · γ = 91.91 °
Ratio a:b:c
1 : 0.839 : 0.471
Z
1
Morphology

Elongated [100] and flattened (100). Dominant faces are (100} and (010); ten other forms were noted in type material.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen3015.999479.970
22.10%
92UUraniumUranium2238.029476.058
21.92%
34SeSeleniumSelenium678.971473.826
21.81%
82PbLeadLead2207.200414.400
19.08%
29CuCopperCopper563.546317.730
14.63%
1HHydrogenHydrogen101.00810.080
0.46%
Total2172.064100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Demesmaekeriet
  • IMA1965-019

In other languages

German
Demesmaekerit · IMA 1965-019
Italian
Demesmaekerite
Chinese
硒铜铅铀矿

Classification

Strunz
10th ed.

4.JJ.20

  • 4OxidesClass
  • 4.JArsenites, antimonites, bismuthites, sulfites, selenites, tellurites; iodatesDivision
  • 4.JJSelenites with additional anions, with H2OGroup
  • 4.JJ.20DemesmaekeriteSpecies
Dana
8th ed.

34.07.06.01

  • 34Selenites, Tellurites and SulfitesClass
  • 34.07Hydrated Selenites, Tellurites and Sulfites containing Hydroxyl or HalogenType
  • 34.07.06— unnamed intermediate level —Group
  • 34.07.06.01DemesmaekeriteSpecies
CIM

28.1.10

  • 28Selenites, Selenates, Tellurites, and TelluratesClass
  • 28.1SelenitesGroup
  • 28.1.10DemesmaekeriteSpecies

Literature, links & citation

Citations
  1. 1965Cesbron, Fabien; Bachet, Bernard; Oosterbosch, Robert (1965) La demesmaekerite, sélénite hydraté d'uranium, cuivre et plomb. Bulletin de Minéralogie, 88 (3). 422-425 doi:10.3406/bulmi.1965.5874 DOI: 10.3406/bulmi.1965.5874
  2. 1966Fleischer, Michael (1966) New Mineral Names. American Mineralogist, 51 (11-12) 1815-1820
  3. 1983Ginderow, D., Cesbron, F. (1983) Structure de la demesmaekerite, Pb2Cu5(SeO3)6(UO2)2(OH)6·2H2O. Acta Crystallographica Section C Crystal Structure Communications, 39 (7) 824-827 doi:10.1107/s0108270183006496DOI: 10.1107/s0108270183006496
  4. 1996Burns, P.C., Hawthorne, F.C. (1996) Static and dynamic Jahn-Teller effects in Cu2+ oxysalt minerals. The Canadian Mineralogist: 34: 1089–1105.
  5. 2005(2005) Demesmaekerite. Handbook of Mineralogy. Mineralogical Society of America
