Denningite

CaMn2+Te4+4O10
IMA status
  • Approved
IMA symbol
Dnn
Discovered
1961
Also known as
  • Denningiet

Where it forms, where it's found

Type locality
Moctezuma Mine
  1. Moctezuma
  2. Moctezuma Municipality
  3. Sonora
  4. Mexico

29.6942°, -109.7125°

3recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Pale green · colorless · pale grey · usually with thin brown coating
Streak
White
Cleavage
Perfect

(001)

Fracture
Conchoidal
Density
5.05 g/cm³

Optical

Optical type
Uniaxial (+) · 2V measured = 15°
Refractive index
1.89 – 2
Surface relief
Very high
Principal indices
nω 1.89 · nε 2.00
UV response
NO fluorescence under LW or SW UV
Notes

May be biaxial

Michel-Lévy diagramhighlighted lineδ = 0.1100
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1100 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1100 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Tetragonal
Space group
P42/nbc
Cell parameters
a = 8.82 Å · c = 13.04 Å
Z
4
Morphology

Eight-sided thin platy crystals, flattened on (001), with (001), (110), and (100).

Type-locality form

Small green cleavable masses. Occasionally as minute colorless euhedral crystals.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
52TeTelluriumTellurium4127.600510.400
66.68%
8OOxygenOxygen1015.999159.990
20.90%
25MnManganeseManganese154.93854.938
7.18%
20CaCalciumCalcium140.07840.078
5.24%
Total765.406100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ca

Synonyms

  • Denningiet

In other languages

German
Denningit
Italian
Denningite
Chinese
碲锌锰石

Classification

Strunz
10th ed.

4.JK.30

  • 4OxidesClass
  • 4.JArsenites, antimonites, bismuthites, sulfites, selenites, tellurites; iodatesDivision
  • 4.JKTellurites without additional anions, without H2OGroup
  • 4.JK.30DenningiteSpecies
Dana
8th ed.

34.04.01.01

  • 34Selenites, Tellurites and SulfitesClass
  • 34.04A(X2O5)Type
  • 34.04.01— unnamed intermediate level —Group
  • 34.04.01.01DenningiteSpecies
CIM

28.3.10

  • 28Selenites, Selenates, Tellurites, and TelluratesClass
  • 28.3TelluritesGroup
  • 28.3.10DenningiteSpecies

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1961Mandarino, J.A., Williams, S.J., Mitchell, R.S. (1961) Denningite, a new tellurite mineral from Moctezuma, Sonora, Mexico. The Canadian Mineralogist: 7: 340-341. (abstract)
  2. 1962Fleischer, Michael; František, Čech (1962) New mineral names. American Mineralogist, 47 (11-12). 1482-1485
  3. 1963Fleischer, Michael (1963) New Mineral Names. American Mineralogist, 48 (11-12) 1413-1421
  4. 1963Mandarino, J. A., Williams, S. J., Mitchell, R. S. (1963) Denningite, a new tellurite mineral from Moctezuma, Sonora, Mexico. The Canadian Mineralogist, 7 (3) 443-452
  5. 1964Walitzi, E. M. (1964) Die Kristallstruktur von Denningit, (Mn, Ca, Zn)Te2O5. Die Naturwissenschaften, 51 (14). 334-335 doi:10.1007/bf00625078DOI: 10.1007/bf00625078
