Donharrisite

Ni3HgS3
IMA status
  • Approved
IMA symbol
Dhr
Discovered
1987
IMA approved
1987
Also known as
  • Donharrisiet
  • IMA1987-007

Where it forms, where it's found

Geological setting

Faulted dolostone stratabound carbonate-hosted Pb-Ag-Hg ore.

Type locality
Erasmus adit
  1. Schwarzleo mining district
  2. Schwarzleograben
  3. Hütten
  4. Leogang
  5. Zell am See District
  6. Salzburg
  7. Austria

47.4254°, 12.6809°

4recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789102/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Brown
Streak
Brownish gray
Tenacity
brittle
Cleavage
Perfect

on (001)

Fracture
Conchoidal
Density
7.27 g/cm³

Optical

Pleochroism
Non-pleochroic
Optical colour
Creamy white with yellowish tint
Anisotropism
Distinct in grayish colors
Bireflectance
Weak
Internal reflections
none
Tropism
Anisotropic
Reflectance R%
(34.0,37.0) 400, (34.9,37.9) 420, (36.2,39.3) 440, (37.9,40.9) 460, (39.6,42.6) 480, (41.3,44.2) 500, (42.8,45.7) 520, (44.2,47.0) 540, (45.4,48.3) 560, (46.5,49.4) 580, (47.5,50.4) 600, (48.4,51.2) 620, (49.2,51.8) 640, (49.8,52.2) 660, (50.4,52.6) 680, (51.1,52.8) 700
Notes

It is significant that optically, the only mineral with which donharrisite might be confused is tuceckite although there are differences of dispersion in their reflectances.

Reflected-light panel
43.7 %anisotropic · dual curve
Specimen sRGB 246, 164, 80
White reference100 % reflector under same lamp
R₁ R₂
Mode
Bireflectance
Weak
Anisotropism
Distinct in grayish colors
Reflected colour
Creamy white with yellowish tint
Internal reflections
none

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 11.574(3) Å · b = 6.899(2) Å · c = 5.419(1) Å
Cell angles
β = 93.71(2) °
Ratio a:b:c
1 : 0.596 : 0.468
Unit cell volume
431.8 ų
Z
4
Morphology

Mica like flakes.

Type-locality form

Mica-like flakes up to 1 mm² by 0.1 mm thick.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
80HgMercuryMercury1200.592200.592
42.42%
28NiNickelNickel358.693176.079
37.24%
16SSulfurSulfur332.06096.180
20.34%
Total472.851100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Donharrisiet
  • IMA1987-007

In other languages

German
Donharrisit · IMA 1987-007
Italian
Donharrisite
Portuguese
Donharrisita · IMA1987-007
Chinese
硫汞镍矿

Classification

Strunz
10th ed.

2.BD.20

  • 2Sulfides and SulfosaltsClass
  • 2.BMetal Sulfides, M: S > 1: 1 (mainly 2: 1)Division
  • 2.BDWith Hg, TlGroup
  • 2.BD.20DonharrisiteSpecies
Dana
8th ed.

02.06.06.01

  • 02SulfidesClass
  • 02.06AmBnXp, with (m+n):p = 4:3Type
  • 02.06.06— unnamed intermediate level —Group
  • 02.06.06.01DonharrisiteSpecies
CIM

3.11.7

  • 3Sulphides, Selenides, Tellurides, Arsenides and Bismuthides (except the arsenides, antimonides and bismuthides of Cu, Ag and Au, which are included in Section 1)Class
  • 3.11Sulphides etc. of NiGroup
  • 3.11.7DonharrisiteSpecies

Literature, links & citation

Citations
  1. 1989Paar, W.H., Chen, T.T., Roberts, A.C., Criddle, A.J., Stanley, C.J. (1989) Donharrisite, nickel-mercury sulfide, a new mineral species from Leogang, Salzburg Province, Austria. The Canadian Mineralogist: 27: 257-262.
  2. 1990Jambor, John L., Vanko, David A. (1990) New Mineral Names. American Mineralogist, 75 (5-6) 706-713
  3. 2005(2005) Donharrisite. Handbook of Mineralogy. Mineralogical Society of America
  4. 2016Bindi, Luca, Paar, Werner H. (2016) Donharrisite, Ni3HgS3: Crystal structure and revision of the chemical formula. Journal of Alloys and Compounds, 682. 248-253 doi:10.1016/j.jallcom.2016.04.304DOI: 10.1016/j.jallcom.2016.04.304
