Dreyerite

Bi(VO4)
IMA status
  • Approved
IMA symbol
Dye
IMA approved
1978
Also known as
  • Dreyeriet
  • IMA1978-077

Where it forms, where it's found

Geological setting

Rhyolitic ash tuff.

Rhyolite tuffs.

Type locality
Hirschhorn
  1. Otterbach-Otterberg
  2. Kaiserslautern
  3. Rhineland-Palatinate
  4. Germany

49.5194°, 7.6778°

4recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102 – 3/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Adamantine
Transparency
Translucent
Colour
Orange-yellow · brownish-yellow
Streak
Yellow
Density
6.25 g/cm³

Optical

Optical type
Uniaxial (+)
Pleochroism
Visible

O = bright yellow E = brownish yellow

Notes

Refractive indicies > 2

Crystallography

Crystal system
Tetragonal
Space group
#178
Cell parameters
a = 7.303(3) Å · c = 6.584(3) Å
Z
4
Morphology

Platy crystals to 0.5 mm.

Type-locality form

Plates parallel (001), 20-50 µm thick, and up to 0.5 mm in diameter.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
83BiBismuthBismuth1208.980208.980
64.51%
8OOxygenOxygen415.99963.996
19.76%
23VVanadiumVanadium150.94250.942
15.73%
Total323.918100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Dreyeriet
  • IMA1978-077

In other languages

German
Dreyerit · IMA 1978-077
Italian
Dreyerite
Chinese
德钒铋矿

Classification

Strunz
10th ed.

8.AD.35

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.APhosphates, etc. without additional anions, without H2ODivision
  • 8.ADWith only large cationsGroup
  • 8.AD.35DreyeriteSpecies
Dana
8th ed.

38.04.08.01

  • 38Anhydrous Normal Phosphates, Arsenates, and VanadatesClass
  • 38.04AXO4Type
  • 38.04.08— unnamed intermediate level —Group
  • 38.04.08.01DreyeriteSpecies
CIM

21.3.12

  • 21Vanadates (and vanadates with arsenate or phosphate)Class
  • 21.3Vanadates of Al, rare earths, Pb, V or BiGroup
  • 21.3.12DreyeriteSpecies

Group, growth & confusion

Commonly confused with
2 minerals

Literature, links & citation

Citations
  1. 1981Dreyer, G. and Tillmanns, E. (1981): Dreyerit: ein natürliches, tetragonales Wismutvanadat von Hirschhorn/Pfalz [Dreyerite: a natural, tetragonal bismuth vanadate from Hirschhorn/Pfalz]. N. Jahrb. Mineral., Monatsh., 1981 (4), 151-154.
  2. 1982Fleischer, M., Cabri, L.J., Chao, G.Y., Mandarino, J.A., Pabst, A. (1982) New mineral names. American Mineralogist: 67: 621-624.
  3. 1982HAZEN, R. M., MARIATHASAN, J. W. E. (1982) Bismuth Vanadate: A High-Pressure, High-Temperature Crystallographic Study of the Ferroelastic-Paraelastic Transition. Science, 216 (4549). 991-993 doi:10.1126/science.216.4549.991DOI: 10.1126/science.216.4549.991
  4. 2005(2005) Dreyerite. Handbook of Mineralogy. Mineralogical Society of America
  5. 2006Frost, Ray L., Henry, Dermot A., Weier, Matt L., Martens, Wayde (2006) Raman spectroscopy of three polymorphs of BiVO4: clinobisvanite, dreyerite and pucherite, with comparisons to (VO4)3-bearing minerals: namibite, pottsite and schumacherite. Journal of Raman Spectroscopy, 37 (7). 722-732 doi:10.1002/jrs.1499DOI: 10.1002/jrs.1499
