Edenharterite

TlPbAs3S6
IMA status
  • Approved
IMA symbol
Eht
Discovered
1992
Also known as
  • Edenharteriet
  • IMA1987-026

Where it forms, where it's found

Geological setting

Hydrothermal deposit in dolostone.

Type locality
Lengenbach Quarry
  1. Fäld
  2. Binn
  3. Goms
  4. Valais
  5. Switzerland

46.3653°, 8.2205°

1recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789102.5 – 3/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent · Opaque
Colour
Brownish-black
Streak
Red
Cleavage
Distinct/Good

One, parallel to (001)

Fracture
Irregular/Uneven
Density
5.09 g/cm³

Optical

Optical type
Biaxial
Optical colour
Grayish white with bluish tint
Anisotropism
Very weak
Internal reflections
Bright red
Tropism
Anisotropic
Reflectance R%
(28.5,30.5) 480, (28.5,31.5) 546, (27.0,28.5) 589, (27.0,29.0) 656
Reflected-light panel
27.8 %anisotropic · dual curve
Specimen sRGB 188, 134, 74
White reference100 % reflector under same lamp
R₁ R₂
Mode
Anisotropism
Very weak
Reflected colour
Grayish white with bluish tint
Internal reflections
Bright red

Crystallography

Crystal system
Orthorhombic
Space group
#23
Cell parameters
a = 15.46 Å · b = 47.5 Å · c = 5.84 Å
Ratio a:b:c
1 : 3.072 : 0.378
Z
16
Type-locality form

Crystals are lathlike.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
33AsArsenicArsenic374.922224.766
27.12%
82PbLeadLead1207.200207.200
25.01%
81TlThalliumThallium1204.380204.380
24.66%
16SSulfurSulfur632.060192.360
23.21%
Total828.706100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Sn

Synonyms

  • Edenharteriet
  • IMA1987-026

In other languages

German
Edenharterit · IMA 1987-026
Italian
Edenharterite
Portuguese
Edenharterita · IMA1987-026
Chinese
艾登哈特尔矿

Classification

Strunz
10th ed.

2.HD.35

  • 2Sulfides and SulfosaltsClass
  • 2.HSulfosalts of SnS archetypeDivision
  • 2.HDWith TlGroup
  • 2.HD.35EdenharteriteSpecies
Dana
8th ed.

03.07.10.02

  • 03SulfosaltsClass
  • 03.07ø = 2Type
  • 03.07.10Simonite GroupGroup
  • 03.07.10.02EdenharteriteSpecies

Group, growth & confusion

Often grow together
1 mineral

Literature, links & citation

Citations
  1. 1983Balić-Žunić, T.; Engel, P. (1983) Crystal structure of synthetic PbTlAs3S6. Zeitschrift für Kristallographie, 165 (1-4). 261-269 doi:10.1524/zkri.1983.165.1-4.261 DOI: 10.1524/zkri.1983.165.1-4.261
  2. 1992Graeser, Stefan, Schwander, Hans (1992) Edenharterite (TlPbAs3S6): a new mineral from Lengenbach, Binntal (Switzerland) European Journal of Mineralogy, 4 (6) 1265-1270 doi:10.1127/ejm/4/6/1265DOI: 10.1127/ejm/4/6/1265
  3. 1996Berlepsch, P. (1996) Crystal structure and crystal chemistry of the homeotypes edenharterite (TlPbAs3S6) and jentschite (TlPbAs2SbS6) from Lengenbach, Binntal (Switzerland) Schweizerische mineralogische und petrographische Mitteilungen, 76. 147-157
  4. 2000Berlepsch, P., Makovicky, E., Balić-Žunić, T. (2000) Contribution to the crystal chemistry of Tl-sulfosalts. VI. Modular-level structure relationship between edenharterite TlPbAs3S6 and jentschite TlPbAs2SbS6. Neues Jahrbuch für Mineralogie - Monatshefte, 2000. 315-332
  5. 2005(2005) Edenharterite. Handbook of Mineralogy. Mineralogical Society of America
