Edgarite

FeNb3S6
IMA status
  • Approved
IMA symbol
Edg
Discovered
1995
IMA approved
1995
Also known as
  • Edgariet
  • IMA1995-017

Where it forms, where it's found

Geological setting

In a feldspar-rich fenitized xenolith approximately 200m across in foyaite at the Khibina alkaline complex.

Type locality
Kaskasnyunchorr Mountain
  1. Murmansk Oblast
  2. Russia

67.7706°, 33.6927°

1recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102 – 2.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Metallic
Transparency
Opaque
Colour
Dark grey
Cleavage
Perfect

basal

Density
4.99 g/cm³

Optical

Pleochroism
Strong

Grey to light grey with a bluish tint

Anisotropism
White to dark brown
Tropism
Anisotropic
Reflectance R%
(28.1, 40.2) 470, (27.4, 39.3) 546, (27.0, 38.5) 589, (27.0, 36.9) 650
Luminescence
nonfluorescent
UV response
nonfluorescent
Notes

Anisotropy strong.

Reflected-light panel
27.4 %anisotropic · dual curve
Specimen sRGB 189, 132, 74
White reference100 % reflector under same lamp
R₁ R₂
Mode
Anisotropism
White to dark brown

Crystallography

Crystal system
Hexagonal
Space group
#104
Cell parameters
a = 5.912(1) Å · c = 12.675(2) Å
Unit cell volume
383.7 ų
Z
2
Type-locality form

Platy inclusions in Ti-(V)-rich pyrrhotite and ferroan alabandite, and as dark gray aggregates of platy grains.

Comment

From Bindi and Martin (2018)

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
41NbNiobiumNiobium392.906278.718
52.89%
16SSulfurSulfur632.060192.360
36.51%
26FeIronIron155.84555.845
10.60%
Total526.923100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • V
  • Mn

Synonyms

  • Edgariet
  • IMA1995-017

In other languages

German
Edgarit · IMA 1995-017
Italian
Edgarite

Classification

Strunz
10th ed.

2.DB.25

  • 2Sulfides and SulfosaltsClass
  • 2.DMetal Sulfides, M: S = 3 :4 and 2:3Division
  • 2.DBM:S = 2:3Group
  • 2.DB.25EdgariteSpecies

Literature, links & citation

Citations
  1. 1970Anzenhofer, K., van den Berg, J.M., Cossee, P., Helle, J.N. (1970) The crystal structures and magnetic susceptibilities of MnNb3S6, FeNb3S6, CoNb3S6 and NiNb3S6. Journal of Physics and Chemistry of Solids: 31: 1057-1067.
  2. 1980Katada, Motomi; Herber, Rolfe H. (1980) Lattice dynamics and hyperfine interactions of the intercalation compounds FexTiS2 (x = 14, 13, and12) and Fe13NbS2 from 57Fe Mössbauer spectroscopy. Journal of Solid State Chemistry: 33: 361-369.
  3. 2000Jambor, John L., Puziewicz, Jacek, Roberts, Andrew C. (2000) New Mineral Names. American Mineralogist, 85 (11-12) 1843-1847
  4. 2000Barkov, A. Y., Martin, R. F., Men'shikov, Y. P., Savchenko, Y. E., Thibault, Y., Laajoki, K. V. O. (2000) Edgarite, FeNb3S6, first natural niobium-rich sulfide from the Khibina alkaline complex, Russian Far North: evidence for chalcophile behavior of Nb in a fenite. Contributions to Mineralogy and Petrology, 138 (3) 229-236 doi:10.1007/s004100050559DOI: 10.1007/s004100050559
  5. 2002Mandarino, Joseph A. (2002) New minerals. The Canadian Mineralogist, 40 (3) 1001-1020 doi:10.2113/gscanmin.40.3.1001 DOI: 10.2113/gscanmin.40.3.1001
