Edoylerite

Hg2+3(Cr6+O4)S2
IMA status
  • Approved
IMA symbol
Eoy
Discovered
1987
IMA approved
1987
Also known as
  • Edoyleriet
  • IMA1987-006
  • IMA1987-008

Where it forms, where it's found

Type locality
Clear Creek claim
  1. Goat Mountain
  2. San Benito County
  3. California
  4. USA

36.3842°, -120.7367°

1recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Transparency
Transparent · Translucent · Opaque
Colour
Canary yellow to orangish yellow
Streak
Yellow
Tenacity
brittle
Cleavage
Distinct/Good

Good (010). Fair (101).

Fracture
Sub-Conchoidal
Density
7.11 g/cm³

Optical

Optical type
Biaxial
Pleochroism
Weak

X = Y = lemon-yellow; Z = darker lemon-yellow.

Optical colour
Pale gray to bluish gray
Internal reflections
Brilliant pale yellow
Tropism
Anisotropic
Reflectance R%
(17.5,16.8) 400, (18.0,18.0) 420, (18.2,19.1) 440, (17.9,19.2) 460, (17.3,18.95) 480, (17.0,18.5) 500, (17.1,19.5) 520, (17.0,19.8) 540, (16.8,19.6) 560, (16.6,19.55) 580, (16.3,19.5) 600, (16.2,19.3) 620, (16.1,19.2) 640, (15.95,19.1) 660, (15.8,19.1) 680, (15.7,18.9) 700
Reflected-light panel
16.8 %anisotropic · dual curve
Specimen sRGB 150, 106, 59
White reference100 % reflector under same lamp
R₁ R₂
Mode
Reflected colour
Pale gray to bluish gray
Internal reflections
Brilliant pale yellow

Crystallography

Crystal system
Monoclinic
Space group
P21/c
Cell parameters
a = 7.52 Å · b = 14.81 Å · c = 7.44 Å
Cell angles
β = 118.72 °
Ratio a:b:c
1 : 1.969 : 0.989
Z
4
Morphology

Elongated on [101] and showing (010), (111), (001), (101).

Type-locality form

Acicular to prismatic crystals.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
80HgMercuryMercury3200.592601.776
76.96%
16SSulfurSulfur232.06064.120
8.20%
8OOxygenOxygen415.99963.996
8.19%
24CrChromiumChromium151.99651.996
6.65%
Total781.888100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Edoyleriet
  • IMA1987-006
  • IMA1987-008

In other languages

German
Edoylerit · IMA 1987-008
Italian
Edoylerite
Portuguese
Edoylerita · IMA1987-008
Chinese
艾德玉莱尔石

Classification

Strunz
10th ed.

7.FB.25

  • 7SulfatesClass
  • 7.FChromatesDivision
  • 7.FBWith additional O,V, S, ClGroup
  • 7.FB.25EdoyleriteSpecies
Dana
8th ed.

35.04.04.01

  • 35Anhydrous ChromatesClass
  • 35.04MiscellaneousType
  • 35.04.04— unnamed intermediate level —Group
  • 35.04.04.01EdoyleriteSpecies

Literature, links & citation

Citations
  1. 1993Erd, Richard C., Bonardi, Maurizio, Criddle, Alan J., Roberts, Andrew C., Page, Yvon Le, Gabe, Eric J. (1993) Edoylerite Hg2+3Cr6+O4S2 a new mineral from the Clear Creek Claim, San Benito County, California. The Mineralogical Record, 24 (6) 471-475
  2. 1994Jambor, John L., Roberts, Andrew C., Vanko, David A. (1994) New Mineral Names. American Mineralogist, 79 (9-10) 1009-1014
  3. 1997Mandarino, Joseph A. (1997) New Minerals 1990-1994. The Mineralogical Record Inc., Tuscon, Arizona. 220pp.
  4. 1999Burns, P.C. (1999) The structure of edoylerite determined from a microcrystal. The Canadian Mineralogist: 37: 113-118.
  5. 2005(2005) Edoylerite. Handbook of Mineralogy. Mineralogical Society of America
