Ellenbergerite

Mg6(Mg,Ti,Zr,◻)2(Al,Mg)6Si8O28(OH)10
IMA status
  • Approved
IMA symbol
Ell
Discovered
1984
IMA approved
1984
Also known as
  • Ellenbergeriet
  • IMA1984-066

Where it forms, where it's found

Geological setting

As inclusions in pyrope porphyroblasts developed during high-pressure (25-30 kbar), medium-temperature (700±C - 800±C) metamorphism of continental crustal rocks.

Type locality
Case Parigi
  1. Martiniana Po
  2. Cuneo Province
  3. Piedmont
  4. Italy
1recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Purple to lilac · some individuals exhibit smoky or pink cores.
Tenacity
brittle
Density
3.15 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.6538 – 1.6789
Surface relief
High
Principal indices
nω 1.6553 – 1.6789 · nε 1.6538 – 1.6697
Pleochroism
Strong

O = colorless; E = colorless to deep lilac

Michel-Lévy diagramhighlighted lineδ = 0.0053
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]53 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation53 nm
Order1st order
XPL colour

Crystallography

Crystal system
Hexagonal
Space group
#104
Cell parameters
a = 12.255(8) Å · c = 4.932(4) Å
Z
1
Type-locality form

Anhedral inclusions in pyrope crystals.

Crystal structure

Chemical composition

Impurities
  • Zr
  • Fe
  • P

Synonyms

  • Ellenbergeriet
  • IMA1984-066

In other languages

German
Ellenbergerit · IMA 1984-066
Italian
Ellenbergerite
Chinese
羟硅钛镁铝石

Classification

Strunz
10th ed.

9.AF.80

  • 9SilicatesClass
  • 9.ANesosilicatesDivision
  • 9.AFNesosilicates with additional anions; cations in [4], [5] and/or only [6] coordinationGroup
  • 9.AF.80EllenbergeriteSpecies
Dana
8th ed.

52.04.10.01

  • 52Nesosilicates Insular Sio4 Groups and O, Oh, F, H2oClass
  • 52.04Insular SiO4 Groups and O, OH, F, and H2O with cations in [6] and/or >[6] coordinationType
  • 52.04.10— unnamed intermediate level —Group
  • 52.04.10.01EllenbergeriteSpecies
CIM

16.14.10

  • 16Silicates Containing Aluminum and other MetalsClass
  • 16.14Aluminosilicates of Ti, Zr, Sn and PbGroup
  • 16.14.10EllenbergeriteSpecies

Literature, links & citation

Citations
  1. 1984Chopin, Christian (1984) Coesite and pure pyrope in high-grade blueschists of the Western Alps: a first record and some consequences. Contributions to Mineralogy and Petrology, 86 (2) 107-118 doi:10.1007/bf00381838DOI: 10.1007/bf00381838
  2. 1985Klaska, R. (1985) Ellen- bergerit, ein neues Hochdruck-Mg-AI-(Ti,Zr)-Silikat mit flächenverknüpfen- den Oktaedern [Ellenbergerite, a new high-pressure Mg-Al-(Ti,Zr) silicate with face-sharing octahedra], in Referate der 24. Diskussionstagung der Arbeitsgemeinschaft Kristallographie der Deutschen Mineralogischen Gesellschaft, der Deutschen Physikalischen Gesellschaft, der Gesellschaft Deutscher Chemiker und der 16. Jahrestagung der Deutschen Gesellschaft für Kristallwachstum und Kristallzüchtung (DGKK) zusammen mit der Kontaktgroep Kristalgroei Nederland (KKN), 19. bis 22. März 1985 in Köln. Zeitschrift für Kristallographie - Crystalline Materials, 170 (1). 93-95 doi:10.1524/zkri.1985.170.14.1DOI: 10.1524/zkri.1985.170.14.1
  3. 1986Chopin, Christian, Klaska, Rolf, Medenbach, Olaf, Dron, Dominique (1986) Ellenbergerite, a new high-pressure Mg-Al-(Ti,Zr)-silicate with a novel structure based on face-sharing octahedra. Contributions to Mineralogy and Petrology, 92 (3) 316-321 doi:10.1007/bf00572160DOI: 10.1007/bf00572160
  4. 1986Chopin, C. (1986) Phase relationships of ellenbergerite, a new high-pressure Mg-Al-Ti-silicate in pyrope-coesite-quartzite from the Western Alps. Geological Society of America Memoir: 164: 31-42.
  5. 1986Chopin, C. (1986) Petrological, crystal-chemical and spectroscopic study of the ellenbergerite group. Fortschritt der Mineralogie: 65: 36-40.
