Embreyite

Pb5(CrO4)2(PO4)2 · H2O
IMA status
  • Approved
IMA symbol
Emb
Discovered
1963
IMA approved
1971
Also known as
  • Embreyiet
  • IMA1971-048

Where it forms, where it's found

Type locality
Berezovsk deposit
  1. Beryozovsky
  2. Sverdlovsk Oblast
  3. Russia

56.9000°, 60.7833°

6recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789103.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Dull orange

Various shades of orange.

Streak
Yellow
Tenacity
brittle
Cleavage
None Observed
Fracture
Irregular/Uneven
Density
6.45 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 10°
Refractive index
2.2 – 2.36
Surface relief
Very high
Principal indices
nα 2.2 · nβ 2.36 · nγ 2.36
Pleochroism
Weak

X = honey-yellow; Y = Z = amber.

Dispersion
relatively strong
Extinction
Y = b.
Michel-Lévy diagramhighlighted lineδ = 0.1600
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1600 nm3rd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1600 nm
Order3rd order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 9.802(16) Å · b = 5.603(9) Å · c = 7.649(12) Å
Cell angles
β = 114.85 °
Ratio a:b:c
1 : 0.572 : 0.780
Unit cell volume
381.2 ų
Z
1
Twinning

Multiple twinning and 60° sector zoning observed optically.

Type-locality form

Thick botryoidal crusts consisting of tiny tabular crystals with the plane of flattening approximately normal to the surface of the crust.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead5207.2001036.000
70.19%
8OOxygenOxygen1715.999271.983
18.43%
24CrChromiumChromium251.996103.992
7.04%
15PPhosphorusPhosphorus230.97461.948
4.20%
1HHydrogenHydrogen21.0082.016
0.14%
Total1475.939100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Embreyiet
  • IMA1971-048

In other languages

German
Embreyit · IMA 1971-048
Italian
Embreyite
Chinese
磷铬铅矿

Classification

Strunz
10th ed.

7.FC.20

  • 7SulfatesClass
  • 7.FChromatesDivision
  • 7.FCWith PO4, AsO4, SiO4Group
  • 7.FC.20EmbreyiteSpecies
Dana
8th ed.

43.03.02.01

  • 43Compound Phosphates, Etc.Class
  • 43.03Hydrated Normal Compound Phosphates, etc·Type
  • 43.03.02— unnamed intermediate level —Group
  • 43.03.02.01EmbreyiteSpecies
CIM

22.5.2

  • 22Phosphates, Arsenates or Vanadates with other AnionsClass
  • 22.5Phosphates, arsenates or vanadates with chromate, molybdate, niobate or tantalateGroup
  • 22.5.2EmbreyiteSpecies

Literature, links & citation

Citations
  1. 1972Williams, S. A. (1972) Embreyite, a new mineral from Berezov, Siberia. Mineralogical Magazine, 38 (299) 790-793 doi:10.1180/minmag.1972.038.299.02 DOI: 10.1180/minmag.1972.038.299.02
  2. 1973Fleischer, M. (1973) New mineral names. American Mineralogist, 58 (7-8). 805-807
  3. 2005(2005) Embreyite. Handbook of Mineralogy. Mineralogical Society of America
  4. 2018Kovrugin, Vadim M., Siidra, Oleg I., Pekov, Igor V., Chukanov, Nikita V., Khanin, Dmitry A., Agakhanov, Atali A. (2018) Embreyite: structure determination, chemical formula and comparative crystal chemistry. Mineralogical Magazine, 82 (2). doi:10.1180/minmag.2017.081.041DOI: 10.1180/minmag.2017.081.041
