Emmonsite

Fe3+2(Te4+O3)3 · 2H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Ems
Discovered
1885
Also known as
  • Durdenite
  • Emmonsiet
  • Emmonsite (of Hillebrand)

Where it forms, where it's found

Geological setting

Oxidized zones of tellurium-bearing ore bodies.

Type locality
Tombstone
  1. Tombstone Mining District
  2. Cochise County
  3. Arizona
  4. USA

31.7128°, -110.0669°

37recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Translucent
Colour
Yellowish-green · light yellow-green in transmitted light.
Cleavage
Perfect

On (010), perfect plus 2 unequal cleavages inclined relative to it, making plane angles of 85° and 95° in (010).

Density
4.52 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 23° · 2V calc = 28 – 48°
Refractive index
1.962 – 2.12
Surface relief
Very high
Principal indices
nα 1.962 · nβ 2.09 · nγ 2.1 – 2.12
Pleochroism
Weak
Dispersion
relatively strong r > v
Michel-Lévy diagramhighlighted lineδ = 0.1480
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1480 nm3rd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1480 nm
Order3rd order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 7.90(1) Å · b = 8.00(1) Å · c = 7.62(1) Å
Cell angles
α = 96.73 ° · β = 95 ° · γ = 84.47 °
Ratio a:b:c
1 : 1.013 : 0.965
Z
2
Morphology

Radially-configured or lichen-like groups of rough, acicular crystals; druses of thin scales; compact microcrystalline masses. Fibrous crusts with a small botryoidal surface to isolated globular aggregates.

Twinning

Observed in microscopic crystals (Goldfield, Nevada).

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
52TeTelluriumTellurium3127.600382.800
56.75%
8OOxygenOxygen1115.999175.989
26.09%
26FeIronIron255.845111.690
16.56%
1HHydrogenHydrogen41.0084.032
0.60%
Total674.511100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Durdenite
  • Emmonsiet
  • Emmonsite (of Hillebrand)

In other languages

French
emmonsite
German
Emmonsit
Spanish
Emmonsita
Italian
Emmonsite
Chinese
碲铁石

Classification

Strunz
10th ed.

4.JM.10

  • 4OxidesClass
  • 4.JArsenites, antimonites, bismuthites, sulfites, selenites, tellurites; iodatesDivision
  • 4.JMTellurites without additional anions, with H2OGroup
  • 4.JM.10EmmonsiteSpecies
Dana
8th ed.

34.03.03.01

  • 34Selenites, Tellurites and SulfitesClass
  • 34.03A2(XO3)3·xH2OType
  • 34.03.03— unnamed intermediate level —Group
  • 34.03.03.01EmmonsiteSpecies
CIM

28.3.21

  • 28Selenites, Selenates, Tellurites, and TelluratesClass
  • 28.3TelluritesGroup
  • 28.3.21EmmonsiteSpecies

Literature, links & citation

Citations
  1. Proceedings of the Colorado Scientific Society: 2: 45-46.
  2. 1885Hillebrand, W.F. (1885) Emmonsite, a ferric tellurite. Proceedings of the Colorado Scientific Society: 2: 20-23.
  3. 1890Dana, E.S, Wells, H.L. (1890) On some selenium and tellurium minerals from Honduras. American Journal of Science: 40: 78-82 (as Durdenite).
  4. 1904Schaller in: Hillebrand, W.F. (1904) Emmonsite (?) from a new locality. American Journal of Science: 18: 433-434.
  5. 1921Larsen, Esper S. (1921) The microscopic determination of the nonopaque minerals. Bulletin 679. US Geological Survey doi:10.3133/b679 DOI: 10.3133/b679
